High Voltage Coaxial/Shielded Cable - 16 AWG, 20 kVDC
High Voltage Coaxial/Shielded Cable - 16 AWG, 20 kVDC
SKU:HIG-c60f40
High Voltage Coaxial/Shielded Cable - 16 AWG, 20 kVDC. Controlled impedance, low capacitance, high impedance. Ideal for military and industrial high voltage applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
High Voltage Coaxial/Shielded Cable - 16 AWG, 20 kVDC
$49.99
Quantity: 1
Claim Your Seller Account
High Voltage Coaxial/Shielded Cable - 16 AWG, 20 kVDC
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The High Voltage Coaxial/Shielded Cable features a conductor gauge of 16 AWG with 19/29 silver-plated copper strands for superior conductivity. Designed for military and industrial high voltage applications like Radar, ECM systems, and power supplies, this cable offers controlled impedance, low capacitance, and high impedance for optimal performance. With an operating temperature range of -55 to 125°C and silver-plated copper shielding strands, this cable ensures reliability and durability in demanding environments. Perfect for connecting Exploding Bridge wire Detonators (EBW) to a Capacitor Discharge Unit (CDU) with fast response times. Order by part number specifying length in feet for seamless interconnections.
Product Specifications
Cable Wire Properties Etched
No
Cable Wire Properties Nomex Jacketed
No
Cable Wire Properties Silicone Coated
No
Cable Wire Properties Wire Type
COAX | Shielded
Shielding Properties Shielding Strands
36 AWG
Shielding Properties Shielding Strand Plating
Silver Plated Copper
Specifications Capacitance At 1k Hz
40 pF/ft
Specifications Conductor Diameter
0.195 in
Specifications Conductor Gauge
16 AWG
Specifications Conductor Material
Copper
Specifications Conductor Plating
Silver Plated
Specifications Conductor Strands
19/29
Specifications Default Color
Natural
Specifications Diameter Over Insulation
0.118 in
Specifications Diameter Over Shield
0.15 in
Specifications Impedance
35 Ω
Specifications Insulator Material
PFA
Specifications Jacket Color
YELLOW
Specifications Jacket Material
PFA
Specifications Operating Temperature
-55 to 125 ºC
Specifications Standardnon Standard
Standard Part
Specifications Voltage Rating
20 kVDC
