High Voltage Female Contact Cable Connector, 15kVDC
High Voltage Female Contact Cable Connector, 15kVDC
SKU:HIG-756a2c
Enhance high-voltage connectivity with our 15kVDC Female Contact Cable Connector. Sealed for altitudes up to 70,000 ft, RoHS compliant.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
High Voltage Female Contact Cable Connector, 15kVDC
$49.99
Quantity: 1
Claim Your Seller Account
High Voltage Female Contact Cable Connector, 15kVDC
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your high-voltage connectivity with our High Voltage Female Contact Cable Connector. Designed for Series 310 operations at reduced pressure, this connector features a sealed receptacle ideal for altitudes up to 70,000 ft. With a current rating of 10 Amp and a voltage rating of 15kVDC, it ensures reliable performance in demanding environments. The brass coupling nut with gold plating ensures secure connections, while the bayonet coupling style simplifies installations. Compliant with RoHS standards, this non-standard part meets institutional procurement requirements with precision and durability.
Product Specifications
Body Properties Coupling Nut Finish
Gold Plated
Body Properties Coupling Nut Material
Brass
Cable Preparation 0
Reynolds Industries Inc. - High Voltage Connectors, High Voltage Cable Assemblies, High Voltage Wire, High Voltage Cable, High Voltage Capacitors _uacct = "UA-425769-1"; urchinTracker(); CLICK HERE FOR A PHOTOGRAPHIC "HOW TO" Series 310 (P/N 167-4356) Step 1 Cut cable to length, clean and square. Slip boot and crimp sleeve over cable. Strip outer jacket to dimension shown. Trim exposed braid to dimension. Trim inner insulation to dimension. No nicked or severed strands allowed. Pot tin dip inner conductor using SN60 solder in accordance with J-STD-006. Remove all flux. Step 2 Solder contact in place through hole using SN60 solder in accordance with J-STD-006. No solder buildup allowed on contact outer diameter. Completed solder joint must have a continuous fillet of solder between the inner conductor and the contact. The solder in the feed hole must be free of pinholes and flush or below flush. Rear of contact shoulder shall be as flush as possible with insulation of cable core, but not to exceed .030". Flair braid by moving cable core in a circular motion. Step 3 Solder contact in place through hole using SN60 solder in accordance with J-STD-006. Completed solder joint must have a continuous fillet of solder between the conductor and the contact. The solder in the feed hole must be free of pinholes and flush or below flush. Rear of contact shoulder shall be as flush as possible with insulation of cable core, but not to exceed .030". Download this page as a PDF for best print quality.
Contact Properties Contact Type
Female
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Receptacle Bag Assembly
Specifications Coupling Style
Bayonet
Specifications Current Rating
10 Amp
Specifications Export Classification
TBD
Specifications Maximum Leak Rate Helium
1 X 10-6 cc/sec
Specifications Mounting Notes
Allow clearance for 1/2-28 UNEF thread
Specifications Operating Temperature
-40 to 85 ºC
Specifications Pressure Differential Rating
Sealed for 1 ATM
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
Yes
Specifications Series
310
Specifications Standardnon Standard
Non-standard Part
Specifications Test Voltage
TBD
Specifications Voltage Rating
15 kVDC
