High-Voltage HT57 Series Ceramic Capacitors
High-Voltage HT57 Series Ceramic Capacitors
SKU:CER-432442
Enhance electronic systems with High-Voltage Ceramic Capacitors - 200 pF, 15 kV, 0.247-5.11 MHz, 10-32 Thread. Ideal for precision applications.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
High-Voltage HT57 Series Ceramic Capacitors
$24.99
Quantity: 1
Claim Your Seller Account
High-Voltage HT57 Series Ceramic Capacitors
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your electronic systems with the high-performance HT57 Series Ceramic Capacitors. These capacitors feature a capacitance of 200 pF, dielectric N750, and a maximum DC voltage of 15 kV. With a frequency range from 0.247 MHz to 5.11 MHz and a current rating of 15.0 A, they offer exceptional reliability and efficiency. Designed with a 10-32 thread and SMAX of 35 kV·A, these capacitors are ideal for applications requiring precision and durability. Compliant with federal procurement standards and industry certifications, these capacitors ensure quality and performance for both consumer and institutional buyers.
Product Specifications
Specifications Cap
200 pF
Specifications Dielectric Tc
N750
Specifications Fh
5.11 MHz
Specifications Fl
0.247 MHz
Specifications Imax Rms
15.0 A
Specifications Smax
35 kV·A
Specifications Thread
10-32
Specifications Vmax Dc
15 kV
