High-Voltage HT57 Series Ceramic Capacitors - 500pF, 15kV
High-Voltage HT57 Series Ceramic Capacitors - 500pF, 15kV
SKU:CER-970977
Enhance electronics with High-Voltage HT57 Series Ceramic Capacitors - 500pF, 15kV. Reliable performance for high-power applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
High-Voltage HT57 Series Ceramic Capacitors - 500pF, 15kV
$29.99
Quantity: 1
Claim Your Seller Account
High-Voltage HT57 Series Ceramic Capacitors - 500pF, 15kV
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your electronic systems with the High-Voltage HT57 Series Ceramic Capacitors. Featuring a capacitance of 500 pF, a maximum DC voltage of 15 kV, and a robust design meeting stringent quality standards, these capacitors ensure reliable performance in high-power applications. Designed for durability and precision, the N5250 dielectric material and 10-32 thread make them ideal for industrial and institutional use. Trust in the HT57 series for superior electrical insulation and optimal efficiency.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Cap
500 pF
Specifications Dielectric Tc
N5250
Specifications Fh
0.433 MHz
Specifications Fl
0.0989 MHz
Specifications Imax Rms
6.90 A
Specifications Smax
35 kV·A
Specifications Thread
10-32
Specifications Vmax Dc
15 kV
