High Voltage Mica Capacitor 15 kVDC - Standard Grade
High Voltage Mica Capacitor 15 kVDC - Standard Grade
SKU:HIG-3f9ab0
Precision-engineered Standard Micapacitors 15 kVDC Rated with 10 nF capacitance, ±10% tolerance, and high voltage rating for reliable performance.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
High Voltage Mica Capacitor 15 kVDC - Standard Grade
$39.99
Quantity: 1
Claim Your Seller Account
High Voltage Mica Capacitor 15 kVDC - Standard Grade
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Standard Micapacitors 15 kVDC Rated are precision-engineered capacitors designed for high energy applications. With a capacitance of 10 nF and a capacitance tolerance of ±10%, these capacitors ensure reliable performance. They feature a 15 kVDC voltage rating, withstanding 18 kV burn-in for 2 hours at 100°C and 21 kV proof for 5 seconds. The mylar wrapping and epoxy end caps provide durability and safety. Ideal for high voltage applications where precision and reliability are paramount.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Cable Preparation Insulation Resistance
25 MΩ*µF at125°C, need not exceed 1GΩ | 4000 MΩ*µF at25°C, need not exceed 100GΩ
Specifications Capacitance
10 nF
Specifications Capacitance Tolerance
±10%
Specifications Dielectric Withstanding Voltage
15 kV rated | 18 kV burn-in for 2 hours at 100°C | 21 kV proof for 5 seconds
Specifications Dissipation Factor
0.005 Max. at 25°C, 1 kHZ
Specifications Length
3.31 in | 84.1 mm
Specifications Standardnon Standard
Standard Part
Specifications Thickness
0.34 in | 8.6 mm
Specifications Voltage Rating
15 kVDC
Specifications Width
2.18 in | 55.4 mm
