High Voltage Mica Capacitors - 15 kVDC Rated
High Voltage Mica Capacitors - 15 kVDC Rated
SKU:HIG-c24e1b
Meet high voltage demands with our 15 kVDC Rated Micapacitors-Best in class for high energy devices!
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
High Voltage Mica Capacitors - 15 kVDC Rated
$24.99
Quantity: 1
Claim Your Seller Account
High Voltage Mica Capacitors - 15 kVDC Rated
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience exceptional performance with our Standard Micapacitors 15 kVDC Rated. With a capacitance of 5 nF and a capacitance tolerance of ±10%, these capacitors offer reliable operation in high energy devices. The mylar wrapped design, epoxy endcaps, and AWG 18 solder coated copper wire leads ensure durability and secure connections. Safety is paramount as the capacitors are shipped with leads shorted for added protection. Trust in our product's superior insulation resistance, dissipation factor, and dielectric withstand voltage of 15 kV rated, meeting stringent industry standards.
Product Specifications
Cable Preparation Insulation Resistance
25 MΩ*µF at125°C, need not exceed 1GΩ | 4000 MΩ*µF at25°C, need not exceed 100GΩ
Specifications Capacitance
5 nF
Specifications Capacitance Tolerance
±10%
Specifications Dielectric Withstanding Voltage
15 kV rated | 18 kV burn-in for 2 hours at 100°C | 21 kV proof for 5 seconds
Specifications Dissipation Factor
0.005 Max. at 25°C, 1 kHZ
Specifications Length
2.81 in | 71.4 mm
Specifications Standardnon Standard
Standard Part
Specifications Thickness
0.31 in | 7.9 mm
Specifications Voltage Rating
15 kVDC
Specifications Width
1.81 in | 46.0 mm
