High Voltage Mica Capacitors 5.0 kVDC Rated
High Voltage Mica Capacitors 5.0 kVDC Rated
SKU:HIG-1d6597
High Voltage Mica Capacitors for high energy applications, 25 nF capacitance, ±10% tolerance, 5.0 kV rated, excellent insulation resistance.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
High Voltage Mica Capacitors 5.0 kVDC Rated
$39.99
Quantity: 1
Claim Your Seller Account
High Voltage Mica Capacitors 5.0 kVDC Rated
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The High Voltage Mica Capacitors 5.0 kVDC Rated offer exceptional performance in high energy applications. With a capacitance of 25 nF and a capacitance tolerance of ±10%, these capacitors ensure precise and reliable operation. Featuring a mylar wrap and epoxy end caps, they provide excellent insulation resistance, meeting stringent industry standards. The capacitors have a dielectric withstanding voltage of 5.0 kV rated, with a 7.5 kV burn-in for 2 hours at 100°C and a 10.0 kV proof for 5 seconds, ensuring durability and safety in demanding environments.
Product Specifications
Cable Preparation Insulation Resistance
25 MΩ*µF at125°C, need not exceed 1GΩ | 4000 MΩ*µF at25°C, need not exceed 100GΩ
Specifications Capacitance
25 nF
Specifications Capacitance Tolerance
±10%
Specifications Dielectric Withstanding Voltage
10.0 kV proof for 5 seconds | 5 kV rated | 7.5 kV burn-in for 2 hours at 100°C
Specifications Dissipation Factor
0.005 Max. at 25°C, 1 kHZ
Specifications Length
2.19 in | 55.6 mm
Specifications Standardnon Standard
Standard Part
Specifications Thickness
0.22 in | 5.6 mm
Specifications Voltage Rating
5 kVDC
Specifications Width
1.32 in | 33.5 mm
