High Voltage Receptacle Sealed, Front Mount - Series 727
High Voltage Receptacle Sealed, Front Mount - Series 727
SKU:HIG-a6a3c7
High Voltage Receptacle Series 727: Reliable, high-performance front mount receptacle for extreme conditions. Silicone sealed with 25 kVDC voltage rating.
Regular price
$34.99
Regular price
Sale price
$34.99
Unit price
per
Initiate Order
High Voltage Receptacle Sealed, Front Mount - Series 727
$34.99
Quantity: 1
Claim Your Seller Account
High Voltage Receptacle Sealed, Front Mount - Series 727
$34.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The High Voltage Receptacle Sealed, Front Mount in Series 727 offers exceptional performance for high reliability applications. With a current rating of 10 Amp and 2.5 Amp, and a voltage rating of 25 kVDC, this receptacle ensures secure connections under extreme conditions. The silicone seal and plastic insulator material provide durability and protection. It boasts compatibility with various connectors and meets stringent leakage rate standards. Mating with LGH 1LI series receptacles enhances operational safety and efficiency.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Body Properties Coupling Nut Material
Plastic
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Receptacle Bag Assembly
Specifications Coupling Style
Threaded
Specifications Current Rating
10 Amp | 2.5 Amp
Specifications Export Classification
TBD
Specifications Insulator Material
Plastic
Specifications Lgh Compatibility
LGH 1LI
Specifications Mating Connectors
Mates all series 727 receptacles and all LGH 1LI series receptacles. Also mates Reynolds C727 receptacle RC1535 ; this combination will reduce the upper operating temperature from +125ºC to +95ºC
Specifications Maximum Leak Rate Helium
1 X 10-6 cc/sec
Specifications Operating Temperature
-55 to 125 ºC
Specifications Panel Mounting Style
Front Mount
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
Yes
Specifications Seal Material
Silicone
Specifications Series
727
Specifications Standardnon Standard
Standard Part
Specifications Test Voltage
25 kVDC at 70,000 ft. (simulated) at ambient temperature
Specifications Voltage Rating
25 kVDC
