High Voltage Red UL 3616 Wire - Perfect for High Current Applications

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The High Voltage Red UL 3616 Wire by Wiremax is designed to meet the demanding needs of various industries, offering a DC voltage rating of up to 60 kV. With a flexible construction featuring 133/0.0177 stranding, this wire provides exceptional ozone and corona resistance. It ranges from 8 AWG to 2 AWG conductors with a 0.269" conductor diameter and a VW-1 flame test compliance. Ideal for heaters, furnaces, motors, and more, this wire is the standard choice for UL 3616 applications.

Product Specifications

Applications 0

HeatersFurnacesOvensDryersMotorsGeneratorsElectronic Equipment Requiring High Voltage and High Current RequirementsCorona Treating Equipment

Note 0

Standard Construction for UL 3616.

Specifications Color

Red

Specifications Conductorstranding Construction

133/0.0177

Specifications Conductor Diameter

0.269 in

Specifications Conductor Size

Specifications Direct Current Dc Voltage

60 kV

Specifications Manufacturer

Wiremax

Specifications Nominal Diameter

0.582 in

Specifications Temperature

150 ÂºC

Specifications Ul Awm File Number

E174208
