High Voltage Single Pin Connector - Series 720

Name: High Voltage Single Pin Connector - Series 720
Brand: Teledyne Reynolds
SKU: HIG-0e6b0f
Price: 69.99 USD
Availability: OutOfStock

SKU:HIG-0e6b0f

Reliable high voltage connector for Military/Aerospace applications. Operating from 10 to 25 kVDC, -55°C to 125°C temperature range. Plug Bag Assembly, threaded coupling, Series 720. Ideal for ECM, TWT connections, lasers.

$69.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Meet the demands of high altitude operations with our HI-REL Single Pin Connector, compatible with LGH™ interfaces. Operating from 10 to 25 kVDC, this connector ensures temperature resistance from -55°C to 125°C. Designed for Military/Aerospace applications, it features annular sealing rings for enhanced altitude performance and plastic bodies to prevent insulator damage. Ideal for Electronic Countermeasure Systems, TWT connections, lasers, and more.

Product Specifications

Body Properties Coupling Nut Material

Plastic

Specifications Altitudereduced Pressure Rating

70,000 ft.

Specifications Assembly Type

Plug Bag Assembly

Specifications Coupling Style

Threaded

Specifications Current Rating

10 Amp | 4 Amp | 6 Amp

Specifications Export Classification

TBD

Specifications Mating Compatibility

Mates all series 720 receptacles and all LGH LI series receptacles. Also mates Reynolds C720 receptacles RC1525 and 3RC1525; this combination will reduce the upper operating temperature from +125ÂºC to +95ÂºC

Specifications Operating Temperature

-55 to 125 ÂºC

Specifications Rohs Compliant

TBD

Specifications Sealed Receptacle

N/A

Specifications Series

720

Specifications Standardnon Standard

Standard Part

Specifications Test Voltage

25 kVDC at 70,000 ft. (simulated) at ambient temperature

Specifications Voltage Rating

20 kVDC
