This high-performance module delivers 50 dB of gain over the broad range of 1 GHz to 3 GHz with a noise figure of less than 2 dB and OIP3 of +33 dBm. The HILNA LS is also usable from 500 MHz to 3.75 GHz with 40 dB of gain (typical). NuWaves’ HILNA LS™ is a broadband low noise amplifier covering L- & S-bands, and designed to achieve extremely high gain while maintaining low noise and a high third order intercept point. The HILNA LS’s small form factor (3.3 inches cubed ) makes it ideal for small communication system installations, co-located to the antenna. The HILNA LS also offers a factory configurable Bias-T option, eliminating the need for a separate power cable run. HILNA LS’s robust power supply also operates over a very broad range, easily allowing the unit to be integrated into systems without regard to power supply precision. Custom Solutions Available: Other Bandwidths Military Screening Form Factors Filtering Gain
Product Specifications
Specifications Export Classification
EAR99
Specifications Gain Typ
50 dB
Specifications Input Supply Vdc
5 - 15
Specifications Maximum Frequency
3000 MHz
Specifications Minimum Frequency
1000 MHz
Specifications Noise Figure Typ
1.7 dB
Specifications Size Lx W X H
2.50 x 1.75 x 0.75 Inch
Specifications Weight
3 oz
