Hope H300 Type - Round Outlet Boxes
Hope H300 Type - Round Outlet Boxes
SKU:H30-b3da10
Durable cast iron outlet boxes with NEMA 3R compliance and stainless steel screws. Ideal for secure surface mounting.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Hope H300 Type - Round Outlet Boxes
$59.99
Quantity: 1
Claim Your Seller Account
Hope H300 Type - Round Outlet Boxes
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Hope H300 Type - Round Outlet Boxes are constructed of durable cast iron, hot dip galvanized for corrosion resistance, and surface-mounted for secure installation. These NEMA 3R and NEM IV compliant units include a box, plain cover with gasket, and stainless steel screws. Mounting lugs drilled for 1/4" bolt provide easy installation. Additional features include tapped pendant covers for various models and drilled and tapped holes through bosses with five threads. With a max conduit size of 1 1/2 inches, outside depth of 4 3/8 inches, and approximate weight of 6.5 lbs, these outlet boxes are robust and reliable for multiple applications.
Product Specifications
Specifications Approx Weight
6.5 lbs
Specifications Construction
cast iron
Specifications Holes Can Be Boss Drilled And Tapped
Holes can be boss, drilled and tapped by Hope Electrical Products at additional cost. Please mark up the hole locations on the attached drilling template and submit with your order to request for quote.
Specifications Inside Depth
2 3/4 in.
Specifications Max Conduit
1 1/2 in.
Specifications Mounting
Surface
Specifications Outside Depth
4 3/8 in.
Specifications Stock Note
If you donât see a box size listed that you need, please inquire - we may have it. This list does not represent all of our boxes.
Specifications Type
H300
