HT57 Series High-Voltage Ceramic Capacitors
HT57 Series High-Voltage Ceramic Capacitors
SKU:CER-eeea0b
High-voltage ceramic capacitors with 150pF capacitance and 15kV VMAX for reliable performance in demanding applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
HT57 Series High-Voltage Ceramic Capacitors
$29.99
Quantity: 1
Claim Your Seller Account
HT57 Series High-Voltage Ceramic Capacitors
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The HT57 Series Ceramic Capacitors are precision-engineered to meet the demanding requirements of high-voltage applications. With a capacitance of 150 pF and a VMAX rating of 15 kV, these capacitors ensure reliable performance in critical systems. The N750 dielectric material provides excellent stability, while the reinforced construction allows for continuous operation under extreme conditions. Ideal for industrial and government projects requiring high-voltage tolerance and superior electrical properties, the HT57 series capacitors offer unmatched reliability and longevity.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Cap
150 pF
Specifications Dielectric Tc
N750
Specifications Fh
6.37 MHz
Specifications Fl
0.330 MHz
Specifications Imax Rms
14.5 A
Specifications Smax
35 kV·A
Specifications Thread
10-32
Specifications Vmax Dc
15 kV
