Hubbell Furnas Pressure Switch - 95/125 PSI, NEMA 1, 1/4in FPT

Name: Hubbell Furnas Pressure Switch - 95/125 PSI, NEMA 1, 1/4in FPT
Brand: Marcuse & Son, Inc.
SKU: HUB-63d048
Price: 79.99 USD
Availability: OutOfStock

SKU:HUB-63d048

Ensure precise pressure control with the Hubbell Furnas Pressure Switch - factory-set at 95/125 PSI, NEMA 1 certified, CSA approved.

$79.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Hubbell Furnas Pressure Switch is a reliable and durable solution for maintaining consistent pressure levels in industrial settings. With factory-set pressures of 95 psi when on and 125 psi when off, this switch ensures precise control. It features a non-metallic cover, visible contacts, and captive cover screw for easy adjustments. Meeting NEMA 1 standards, it offers an automatic unloader valve, ample wiring space, and two ground screws for added convenience. Certified by CSA, this switch also includes a pulsation dampener, making it a versatile and compliant choice for various applications.

Product Specifications

Factory Set Pressure Factory Set Pressure When Off

125 psi

Factory Set Pressure Factory Set Pressure When On

95 psi

Note 0

Maximum pressure on 69MB7Series is 150 psiThese units have the 4 port manifold

Power Rating 3 Phase Power Rating At 115 V

3 hp

Power Rating Single Phase Power Rating At 115 V

1-1/2 hp

Power Rating Single Phase Power Rating At 230 V

2 hp

Power Rating Voltage

115 V | 230 V

Specifications Brand

Hubbell

Specifications Female Pipe Thread Fpt Pipe Size

1/4 in

Specifications Industry Standards

NEMA 1

Specifications Maximum Pressure

150 psi

Specifications Mounting

Bottom

Specifications Number Of Port

Specifications Offon Lever

Yes

Specifications Phase

1 | 3

Specifications Unloaded Valve

Yes
