HUBER+SUHNER SK Precision Subminiature Straight Cable Connectors (Plug)

HUBER+SUHNER SK Precision Subminiature Straight Cable Connectors (Plug)

SK2-ba69f4

High-performance 50 Ohm SK Precision Subminiature Straight Cable Connectors for reliable signal transmission up to 40GHz.

$49.99
$49.99
Sale

Initiate Order

HUBER+SUHNER SK Precision Subminiature Straight Cable Connectors (Plug)

HUBER+SUHNER SK Precision Subminiature Straight Cable Connectors (Plug)

$49.99

Quantity: 1

Claim Your Seller Account

HUBER+SUHNER SK Precision Subminiature Straight Cable Connectors (Plug)

HUBER+SUHNER SK Precision Subminiature Straight Cable Connectors (Plug)

$49.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The HUBER+SUHNER SK Precision Subminiature Straight Cable Connectors offer exceptional performance for high-frequency applications. With an impedance of 50 Ohms and frequency range up to 40GHz, these connectors ensure reliable signal transmission. Featuring beryllium-copper hardened construction, they provide superior durability and can withstand temperatures from -67 to 257 degrees F. Designed for semi-rigid cables with male connection and straight configuration, these connectors meet the stringent requirements of government and institutional procurement standards.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Specifications Body Material
beryllium-copper hardened
Specifications Cable Group
Y10
Specifications Cable Type
semi-rigid
Specifications Centre Contacts
beryllium-copper hardened
Specifications Centre Contact Resistance M Ohms
<3
Specifications Configuration
straight
Specifications Connection
male
Specifications Connector Series
SK
Specifications Contact Captivation Lbs
>4.9
Specifications Dielectic Withstanding Voltage Sea Level V Rms
750
Specifications Durability Matings
>500
Specifications Frequency Ghz
DC...40
Specifications Impedance Ohms
50
Specifications Insulation Resistance M Ohms
>5000
Specifications Outside Contact Resistance M Ohms
<2
Specifications Packaging
single
Specifications Support Beads
PPO
Specifications Temperature Range Degrees F
-67 to 257
Specifications Working Voltage Sea Level V Rms
<250
