HUBER+SUHNER SMA Female Straight PCB Jacks

Name: HUBER+SUHNER SMA Female Straight PCB Jacks
Brand: C. W. Swift & Associates, Inc.
SKU: SMA-18b46c
Price: 89.99 USD
Availability: OutOfStock

SKU:SMA-18b46c

High-quality HUBER+SUHNER SMA Female Straight PCB Jacks for reliable signal transmission in electronic applications.

$89.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The HUBER+SUHNER SMA Female Straight PCB Jacks are precision-engineered subminiature connectors designed for high-performance applications. With a cable dielectric diameter of .066/.117 inches and an impedance of 50 ohms, these connectors ensure reliable signal transmission. Operating within a frequency range of DC - 18 GHz, they are ideal for demanding electronic setups. The connectors feature SUCOPLATE body plating, enabling enhanced durability. Designed as straight PCB jacks with a mounting hole of ML 41, these connectors offer a secure and stable connection for seamless integration into your systems. Whether for consumer electronics or institutional installations, these connectors deliver superior quality and performance.

Product Specifications

Specifications Cable Dielectic Dia Inches

.066/.117

Specifications Configuration

straight PCB jack

Specifications Connection

female

Specifications Connector Series

SMA

Specifications Frequency Range Ghz

DC - 18

Specifications Impedence Ohms

Specifications Mounting Hole

ML 41

Specifications Packaging

bulk 100 pcs.

Specifications Plating Body

SUCOPLATE

HUBER+SUHNER SMA Female Straight PCB Jacks
