HYBRIDFLUSH Automatic Low Consumption Urinal Flush Valve
HYBRIDFLUSH Automatic Low Consumption Urinal Flush Valve
SKU:HIG-ef4ab1
Efficient and reliable HYBRIDFLUSH Automatic Urinal Flush Valve for commercial & institutional use. Sensor-operated, water-saving design.
Regular price
$279.99
Regular price
Sale price
$279.99
Unit price
per
Initiate Order
HYBRIDFLUSH Automatic Low Consumption Urinal Flush Valve
$279.99
Quantity: 1
Claim Your Seller Account
HYBRIDFLUSH Automatic Low Consumption Urinal Flush Valve
$279.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your restroom with the HYBRIDFLUSH Automatic Low Consumption Urinal Flush Valve. This top-mount system features a sensor-operated mechanism for efficient water usage. With a durable chrome metal casing, this flush valve offers automatic and manual operation, ensuring reliability and water conservation. The patented design allows for alternative flushing options independent of battery power, making it an economical and efficient choice. Meeting ASSE 1037, ASME A112.1035, and CSA B125.37 standards, the HYBRIDFLUSH is a top-performing solution for commercial and institutional settings.
Product Specifications
Specifications Arming Delay Time
5 s
Specifications Battery Life
>3 year
Specifications Battery Type
Four AA Alkaline Batteries
Specifications Compliance And Certifications
American Society of Safety Engineers (ASSE) 1037-2015American Society of Mechanical Engineers (ASME) A112.1035-2015Canadian Standards Association (CSA) B125.37-15
Specifications Flush Mode
After Every Use
Specifications Ghost Flush
Once Every 24 Hours from Last Flush
Specifications Manual Override
Mechanical Flush Button or None
Specifications Maximum Static Pressure
80 psi
Specifications Minimum Flowing Pressure
25 psi
Specifications Minimum Flow Rate
18 gpm
Specifications Operating Water Pressure
15 to 100 psi
Specifications Operation
Hybrid (Automatic/Manual)
Specifications Outer Casing
Standard-Chrome Metal
Specifications Sensing Range
18 to 30 in | 45 to 75 cm
Specifications Sensor Angle
Adjustable Angle
Specifications Sensor Type
Infrared
Specifications Specifications
Patented BRV® and Gear Motor DriveHands Free Infrared Sensor ActivationVandal and Water Resistant DesignChrome Plated All Metal HousingQuiet OperationTrue Mechanical Override (Side) *Mechanical Button/Handle Works When Batteries are DrainedOperates on (4) âAAâ Alkaline Batteries (Included)Battery Life - 3+ YearsâLow Batteryâ Blinking LED IndicatorEasy Battery Replacement-No Water Shut Off NecessaryAdjustable Sensor AngleAdjustable Sensor DistanceOptional Water Saver ModeOptional Three (3) Second Flush Delay ModeOptional 24-Hour Flush ModeUses Proprietary Silicone Diaphragm with Filtered Bypass3/4 Inch (in) I.P.S. Angle StopAdjustable TailpieceHigh Back Pressure Vacuum Breaker with Single Piece Hex Coupling NutSpud Coupling and Flange for 3/4 Inch (in) Top SpudSweat Solder Kit and Wall Flange with Set ScrewLow Consumption For Water Conservation
Specifications The Hybridflush Advantage
The HYBRIDFLUSH® is a revolutionary full-featured automatic/manual flush valve system. The HYBRIDFLUSH® incorporates a unique patented mechanism that allows for automatic/manual operation for unsurpassed reliability. The patented HYBRIDFLUSH® design allows for the original flush handle or push button to be used as an alternate flush option that is independent of the battery power. The HYBRIDFLUSH® by Advanced Modern Technologies Corporation is the most efficient, economical, and complete automatic flush valve system on the market.
Specifications Water Saver Mode
After Every Other Use
