HYDAC RS Hydraulic Filter Element 0330 RS 125 W
HYDAC RS Hydraulic Filter Element 0330 RS 125 W
SKU:HYD-ee4900
High-performance HYDAC RS Filter Element for Return/Suction Filters, 125 µm rating, stainless steel mesh, Nitrile Rubber seal.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
HYDAC RS Hydraulic Filter Element 0330 RS 125 W
$39.99
Quantity: 1
Claim Your Seller Account
HYDAC RS Hydraulic Filter Element 0330 RS 125 W
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The HYDAC Filter Elements Type RS are precision-engineered for Return/Suction Filters, designed with a 125 µm filter rating, stainless steel mesh material, and Nitrile Rubber seals. These cartridge-style elements feature durable plastic caps, a steel support tube, and are flow-efficient with Inside-Out flow direction. With a collapse rating of 20 bar, these elements ensure reliable filtration performance in hydraulic systems. Ideal for hydraulic and lube filters, they meet stringent industry standards for quality and durability.
Product Specifications
Dimensions Dimension Id1
1.89 in
Dimensions Height
7.7 in | 196 mm
Dimensions Inside Diameter 1
40.2 mm
Dimensions Outside Diameter 1
3 in | 77 mm
Specifications Bun
EA
Specifications Bypass Pressure
0.3 bar | 4.4 psi
Specifications Cap 1 Material
Plastic
Specifications Cap 1 Type
O-Ring Cap
Specifications Cap 2 Material
Plastic
Specifications Cap 2 Type
Bypass Cap
Specifications Collapse Rating
20 bar
Specifications Configuration
One Open Cap, One Bypass Cap
Specifications Division
HYDRAULIC AND LUBE FILTERS
Specifications Filter Material
Stainless Steel Mesh
Specifications Filter Rating
125 µm
Specifications Flow Direction
Inside - Out
Specifications Maximum Temperature
100 ºC | 212 ºF
Specifications Media Type
W=Stainless Steel Wire Mesh
Specifications Minimum Temperature
-30 ºC | -22 ºF
Specifications Model Code Description
0330 RS 125 W
Specifications Nominal Filter Rating
125 µm
Specifications Outer Sleeve
No
Specifications Product
HYDAC ELEMENTS
Specifications Product Group Family
ELEMENTS-HYDAC PROPRIETARY
Specifications Seal
Nitrile Rubber (NBR)
Specifications Size
0330
Specifications Stat Free
No
Specifications Style
Cartridge
Specifications Support Tube Material
Steel
Specifications Type
Hydraulic Filter Element
