Hydraulic Check Valve Female Tee Needle Valve BSP Parallel
Hydraulic Check Valve Female Tee Needle Valve BSP Parallel
SKU:FIT-eb204b
Durable Hydraulic Check Valve with 350 bar pressure rating, ideal for various hydraulic systems.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Hydraulic Check Valve Female Tee Needle Valve BSP Parallel
$59.99
Quantity: 1
Claim Your Seller Account
Hydraulic Check Valve Female Tee Needle Valve BSP Parallel
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Hydraulic Check Valve Female Tee Needle Valve BSP Parallel is a versatile solution combining extra light duty, heavy duty, and light duty pressure options. With a nominal operating pressure of 350 bar and high-quality carbon steel construction, this valve offers durability and reliability in hydraulic systems. Its precise G - Thread Size of 1/2 ensures secure fittings, while dimensions of L1: 41.0 mm, L2: 64 mm, and CH1: 27 mm provide efficient installation flexibility. This valve is designed to meet rigorous institutional procurement standards, making it ideal for a wide range of applications.
Product Specifications
Specifications Ch1
27 mm
Specifications G Thread Size
1/2
Specifications L1
41.0 mm
Specifications L2
64 mm
Specifications Material
Carbon Steel
Specifications Nominal Operating Pressure
350 bar
Specifications Pressure
Extra Light Duty | Heavy Duty | Light Duty
