Hydraulic Foot Operated Pumps - FSP-A & FSP-PL Series
Hydraulic Foot Operated Pumps - FSP-A & FSP-PL Series
SKU:HYD-e5e6e1
Enhance hydraulic system pressure manually with the reliable FSP-A & FSP-PL Foot Operated Pumps. Maximum 5000 PSI rating, ideal for emergencies.
Regular price
$428.00
Regular price
Sale price
$428.00
Unit price
per
Initiate Order
Hydraulic Foot Operated Pumps - FSP-A & FSP-PL Series
$428.00
Quantity: 1
Claim Your Seller Account
Hydraulic Foot Operated Pumps - FSP-A & FSP-PL Series
$428.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Hydraulic Foot Operated Pumps from the FSP-A & FSP-PL Series are designed for equipment with existing reservoirs, providing an affordable solution for increasing hydraulic system pressure manually. These pumps, available in hand or foot-operated versions, offer a maximum pressure rating of 5000 PSI. With a sturdy steel body and hard chrome plated piston, they ensure reliable hydraulic power for various applications. Ideal for emergencies, these pumps are commonly used in medical, food handling, and corrosive environments. The FSP-PL series features a flange mount version for added versatility.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Adjustable Overload Relief Valve
No
Specifications Body Material
Steel
Specifications Foot Lever Load Per 100 Psi
2.3 lb
Specifications Inlet Port Size Nptf
3/8
Specifications List Price
428 USD
Specifications Manual Pressure Release Valve
No
Specifications Maximum Pressure Rating
5000 psi
Specifications Mounting
Flange Mounted
Specifications Net Weight
11 lb
Specifications Oil Reservoir
false
Specifications Operating Lever Size
24 in
Specifications Outlet Port Size Nptf
3/8
Specifications Piston
Hard Chrome Plated
Specifications Piston Diameter
1/2 in
Specifications Series
FSP-PL
Specifications Volume Per Stroke
0.29 in³
Technical Information 0
Limited WarrantyAll Star pumps are covered by a limited warranty on materials and workmanship for one year from the date of manufacture. Star will repair or replace at its option any pump in which Star finds manufacturing defects. In order to get warranty service a pump must be returned to the Star plant freight prepaid with a written explanation of the problem.Technical DataLight hydraulic oil is recommended for use with Star pumps. Oils with SUS viscosity of 75 to 150 at 100 degrees Fahrenheit will give satisfactory performance (ISO grade 15, 22, or 32). In an emergency situation when the above oils are not available, use 5 W or 10 W motor oil or automatic transmission fluid.All exposed surfaces of standard Star pumps are painted with one coat of industrial quality paint. Pumps painted with special colors with two coat finishes, or with prime coat only, and pumps with special plated or polished parts, are also available.
