Hydraulic Foot Pumps - FSP-A & FSP-PL Series
Hydraulic Foot Pumps - FSP-A & FSP-PL Series
SKU:HYD-ca686e
Reliable Hydraulic Foot Pumps for emergency hydraulic power needs in various environments.
Regular price
$411.00
Regular price
Sale price
$411.00
Unit price
per
Initiate Order
Hydraulic Foot Pumps - FSP-A & FSP-PL Series
$411.00
Quantity: 1
Claim Your Seller Account
Hydraulic Foot Pumps - FSP-A & FSP-PL Series
$411.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Hydraulic Foot Pumps - FSP-A & FSP-PL Series offer a reliable solution for developing and increasing pressure in hydraulic systems. These pumps, available in both hand and foot-operated versions, are designed without oil reservoirs but feature hard chrome plated pistons for durability. With a maximum pressure rating of 5000 PSI, they are utilized as standby pumps for emergencies, providing hydraulic power for various applications like presses, valves, and safety locks. Ideal for medical, food handling, and corrosive environments, these pumps are a cost-efficient choice for institutions needing dependable hydraulic power.
Product Specifications
Specifications Adjustable Overload Relief Valve
No
Specifications Body Material
Steel
Specifications Foot Lever Load Per 100 Psi
37.0 lb
Specifications Inlet Port Size Nptf
3/8
Specifications List Price
411 USD
Specifications Manual Pressure Release Valve
No
Specifications Maximum Pressure Rating
250 psi
Specifications Mounting
Base Mounted
Specifications Net Weight
11 lb
Specifications Oil Reservoir
false
Specifications Operating Lever Size
24 in
Specifications Outlet Port Size Nptf
3/8
Specifications Piston
Hard Chrome Plated
Specifications Piston Diameter
2 in
Specifications Series
FSP
Specifications Volume Per Stroke
4.71 in³
Technical Information 0
Limited WarrantyAll Star pumps are covered by a limited warranty on materials and workmanship for one year from the date of manufacture. Star will repair or replace at its option any pump in which Star finds manufacturing defects. In order to get warranty service a pump must be returned to the Star plant freight prepaid with a written explanation of the problem.Technical DataLight hydraulic oil is recommended for use with Star pumps. Oils with SUS viscosity of 75 to 150 at 100 degrees Fahrenheit will give satisfactory performance (ISO grade 15, 22, or 32). In an emergency situation when the above oils are not available, use 5 W or 10 W motor oil or automatic transmission fluid.All exposed surfaces of standard Star pumps are painted with one coat of industrial quality paint. Pumps painted with special colors with two coat finishes, or with prime coat only, and pumps with special plated or polished parts, are also available.
