Hydraulic Foot Pumps - FSP-A & FSP-PL Series
Hydraulic Foot Pumps - FSP-A & FSP-PL Series
SKU:HYD-787097
Reliable hydraulic foot pumps without reservoir or overload relief. Ideal for emergency use with max 1250 psi. Steel construction with chrome-plated piston.
Regular price
$431.00
Regular price
Sale price
$431.00
Unit price
per
Initiate Order
Hydraulic Foot Pumps - FSP-A & FSP-PL Series
$431.00
Quantity: 1
Claim Your Seller Account
Hydraulic Foot Pumps - FSP-A & FSP-PL Series
$431.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Hydraulic Foot Pumps - FSP-A & FSP-PL Series offer reliable hydraulic power without the need for an oil reservoir, overload relief valve, or manual pressure release valve. Ideal for equipment with existing reservoirs and control valves, these pumps serve as a cost-effective solution to develop or increase pressure in hydraulic systems. Available in both hand and foot-operated versions, with a maximum pressure rating of 1250 psi, these pumps are designed for emergency use to operate presses, valves, safety locks, and more. The steel construction features a hard chrome-plated piston for durability and efficient performance. With options for stainless steel or bronze piston designs, these pumps are suitable for medical, food handling, corrosive environments, and wash-down applications.
Product Specifications
Specifications Adjustable Overload Relief Valve
No
Specifications Body Material
Steel
Specifications Foot Lever Load Per 100 Psi
9.2 lb
Specifications Inlet Port Size Nptf
3/8
Specifications List Price
431 USD
Specifications Manual Pressure Release Valve
No
Specifications Maximum Pressure Rating
1250 psi
Specifications Mounting
Flange Mounted
Specifications Net Weight
11 lb
Specifications Oil Reservoir
false
Specifications Operating Lever Size
24 in
Specifications Outlet Port Size Nptf
3/8
Specifications Piston
Hard Chrome Plated
Specifications Piston Diameter
1 in
Specifications Series
FSP-PL
Specifications Volume Per Stroke
1.18 in³
Technical Information 0
Limited WarrantyAll Star pumps are covered by a limited warranty on materials and workmanship for one year from the date of manufacture. Star will repair or replace at its option any pump in which Star finds manufacturing defects. In order to get warranty service a pump must be returned to the Star plant freight prepaid with a written explanation of the problem.Technical DataLight hydraulic oil is recommended for use with Star pumps. Oils with SUS viscosity of 75 to 150 at 100 degrees Fahrenheit will give satisfactory performance (ISO grade 15, 22, or 32). In an emergency situation when the above oils are not available, use 5 W or 10 W motor oil or automatic transmission fluid.All exposed surfaces of standard Star pumps are painted with one coat of industrial quality paint. Pumps painted with special colors with two coat finishes, or with prime coat only, and pumps with special plated or polished parts, are also available.
