Hydraulic Male Stud Non Return Valve with BSP Parallel Threads
Hydraulic Male Stud Non Return Valve with BSP Parallel Threads
SKU:VAL-49b656
Durable Hydraulic Non Return Valve for DIN Check Valve applications with BSP Parallel Threads. Pressure range: Extra Light Duty to Heavy Duty.
Regular price
$55.99
Regular price
Sale price
$55.99
Unit price
per
Initiate Order
Hydraulic Male Stud Non Return Valve with BSP Parallel Threads
$55.99
Quantity: 1
Claim Your Seller Account
Hydraulic Male Stud Non Return Valve with BSP Parallel Threads
$55.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Hydraulic Male Stud Non Return Valve with BSP Parallel Threads is designed for exceptional performance in hydraulic systems. With options for Extra Light Duty, Heavy Duty, and Light Duty pressures, it offers reliable operation at up to 350 bar nominal pressure. Crafted from durable Carbon Steel, this valve features a 10mm M-Tube Diameter, 3/8in W-Tube Diameter, 1/4 G-Thread Size, and precision engineering for a Diameter Pass of 4mm. Ideal for DIN Check Valve applications, this valve is a sturdy and dependable choice for demanding hydraulic environments.
Product Specifications
Specifications Ch1
19.0 mm
Specifications Diameter Pass
4 mm
Specifications G Thread Size
1/4
Specifications Jic 37 Thread
9/16-18
Specifications L1
64.1 mm
Specifications L2
12.0 mm
Specifications Material
Carbon Steel
Specifications M Tube Diameter
10 mm
Specifications Nominal Operating Pressure
350 bar
Specifications Pressure
Extra Light Duty | Heavy Duty | Light Duty
Specifications W Tube Diameter
3/8 in
Category 6
Male Stud Non Return Valve with Elastomer Seal Thread BSP Parallel
