Hydraulic Single Braid Hose - 100R1AT (Medium Pressure)

Name: Hydraulic Single Braid Hose - 100R1AT (Medium Pressure)
Brand: Seal Fast, Inc.
SKU: HOS-3b99ca
Price: 59.99 USD
Availability: OutOfStock

SKU:HOS-3b99ca

Premium Hydraulic Single Braid Hose - 100R1AT (2000 psi, -40 to +250°F). Meets SAE J517 100R1AT standards.

$59.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Hydraulic Single Braid Hose - 100R1AT (Medium Pressure) is a premium-quality hydraulic hose suitable for mineral oil and glycol base liquids. This hose exceeds SAE J517 100R1AT standards, ensuring reliable performance in demanding environments. With a working pressure of 2000 psi and a temperature range of -40 to +250°F, this hose is designed to withstand extreme conditions. It features a robust construction with oil and weather-resistant synthetic rubber cover, oil-resistant synthetic rubber tube, and one steel wire braid reinforcement, providing durability and flexibility. Ideal for both consumer and institutional applications, this hose offers exceptional strength and performance.

Product Specifications

Specifications Bend Radius

7 in

Specifications Burst Pressure 70

8000 psi

Specifications Cover

Oil and Weather Resistant Synthetic Rubber

Specifications Id

1/2 in

Specifications Od

0.82 in

Specifications Package Type

Feet

Specifications Reinforcement

One Steel Wire Braid

Specifications Temperature Range

-40 to +250 ÂºF

Specifications Tube

Oil Resistant Synthetic Rubber

Specifications Weight Per 100 Foot

26.2 lb

Specifications Working Pressure

2000 psi

Hydraulic Single Braid Hose - 100R1AT (Medium Pressure)
