Hydro-Pac Li'I CRITTER Single Stage Gas Compressor
Hydro-Pac Li'I CRITTER Single Stage Gas Compressor
SKU:ACT-8267dc
Compact, powerful single stage gas compressor for lab and production applications, 12000 psi discharge pressure.
Regular price
$2,899.99
Regular price
Sale price
$2,899.99
Unit price
per
Initiate Order
Hydro-Pac Li'I CRITTER Single Stage Gas Compressor
$2,899.99
Quantity: 1
Claim Your Seller Account
Hydro-Pac Li'I CRITTER Single Stage Gas Compressor
$2,899.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Hydro-Pac Li'I CRITTER Single Stage Gas Compressor is a compact powerhouse designed for laboratory and production applications, offering reliability and longevity in a smaller footprint. With a discharge pressure of 12000 psi and a power of 3 hp, this compressor features an oil-free design for minimal contamination risk and efficient performance. Its patented free-piston design allows for quick high-pressure seal replacement without extensive disassembly, while the compact self-contained unit saves space. Ideal for hot isostatic pressing, pneumatic testing, chemical processing, and more, it comes equipped with standard electric motor, hydraulic power unit, and safety features.
Product Specifications
Key Features Benefits And Advantages 0
One Piece Body and Disc in PVC, CPVC and GFPP MaterialsRevolutionary Hand Lever with 19 Lockable Stop Positions and 360° InterlockExternal Disc Position and Flow IndicationHydro-dynamic Centric Disc Design for Increased Flow PerformanceOver-Sized Liner Face Maximizes Surface Contact with FlangesEPDM, Viton® or Nitrile Liners1-Piece 316 Stainless Steel Stem with Threaded Retaining GlandStem Bearing and Seal Retainer for Absolute Stem Positioning and SealingISO 5211 Top Flange and Stem DriveAll Sizes Meet ANSI B16.10 / ISO 5752 Narrow Face-to-Face Dimensions
Materials 0
PVC per ASTM D1784 Cell Class 12454CPVC per ASTM D1784 Cell Class 23447GFPP per ASTM D4101 Cell Class 85580EPDM, Viton® and Nitrile Liners
Options 0
Over-Molded or Field Mountable 316 Stainless Steel LugsGear OperatorsComplete Range of Pneumatic or Electric ActuatorsStem Extensions2" Square Operating NutChain Operator for Gear Box
Sample Specifications Valve 0
All thermoplastic wafer-style butterfly valves shall be manufactured from PVC Type 1, Grade 1 (ASTM D1784, Cell Classification 12454), CPVC(ASTM D1784, Cell Classification 23447) or glass filled Polypropylene (ASTM D4101, Cell Classification 85580). All valve bodies shall containintegral top mounting flange with dimensions and bolt circles conforming to ISO 5211. Bodies shall contain fully-supported flange bolt holes,be one piece construction and meet ANSI B16.10 narrow face-to-face dimensions in all sizes. If LUGGED butterfly valves are required, lugsshall be over-molded, 316 stainless steel and be the full width of the body. Liners shall be EPDM, Viton® or Nitrile. Liner shall be FULL BOOTdesign, and shall be retained in the body via rib and groove engagement. Liner shall serve as primary disc seal and face seals for mating flanges.Secondary upper bearing and lower seal retainer o-ring seals to be EPDM or FPM. Stem shall be 316 stainless steel, non-wetted and providefull engagement over length of disc. Stem shall have position retention design.All sizes of butterfly valves (2" through 12") shall be pressure-rated for 150 PSI at 70°F non-shock.All butterfly valves shall carry a three-year warranty, and shall be manufactured by Hayward Flow Control products in the USA.
Specifications Actuator Type
Electric
Specifications Enclosure
NEMA4/4X
Specifications Enclosure Material
Glass Filled Polypropylene
Specifications Flow Coefficient Cv
280
Specifications Iso 5211 Flange Drive
F07-D11
Specifications Liner Material
Viton®
Specifications Medium Temperature Range
70 ºF
Specifications Method Of Operation
Actuated
Specifications Operation
On / Off
Specifications Pressure Rating At 70f
10 bar | 150 psi
Specifications Standard Voltage
24VAC/VDC, 120V & 230V
Specifications Valve Body Material
PVC
Specifications Valve Disc Material
PVC
Specifications Valve Size
3"
Applications 0
Water and Wastewater TreatmentAquatic and Animal Life Support SystemsChemical Processing and HandlingMarine and Corrosive EnvironmentsMiningMetal Plating and Surface FinishingLandfills / Environmental InfrastructureWater / Theme Parks
