Incoloy 800HT Nickel Alloy Sheet

Name: Incoloy 800HT Nickel Alloy Sheet
Brand: Continental Steel & Tube Co.
SKU: NIC-c65fd0
Price: 250.0 USD
Availability: OutOfStock

SKU:NIC-c65fd0

Premium Incoloy 800HT Nickel Alloy Sheet for high-temperature environments, exceptional strength, and corrosion resistance

$250.00

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Incoloy 800HT Sheet is a premium nickel-iron-chromium alloy known for its exceptional strength, high-temperature oxidation resistance, and durability in corrosive environments. With a stable austenitic structure, this sheet is ideal for applications in process piping, heat exchangers, carburizing equipment, and more. Compliant with ASME SB-409, ASTM B409, and UNS N08811 standards, this sheet offers superior performance and reliability in demanding industrial settings.

Product Specifications

Nickel Alloy Compositions Alloy

Incoloy 800HT

Nickel Alloy Compositions Astm Specification

ASME SB-409 | ASTM B409 | UNS N08811

Nickel Alloy Compositions Basic Composition

Nickel Alloy Compositions Density

0.287 lbs/inÂ³ | 7.94 g/cmÂ³

Specifications Material

IncoloyÂ®

Specifications Shapeform

Sheets

Specifications Thickness

0.060 inches | 1.524 mm

Mechanical Properties Melting Temperature Range

2475 to 2525 ÂºF | 1357 to 1385 ÂºC

Mechanical Properties Rupture Strength 1000 H At 1200f65

24000 psi | 165 MPa

Mechanical Properties Rupture Strength 1000 H At 1300f70

15000 psi | 105 MPa

Mechanical Properties Rupture Strength 1000 H At 1400f76

10000 psi | 70 MPa

Mechanical Properties Rupture Strength 1000 H At 1600f87

4700 psi | 32 MPa

Mechanical Properties Rupture Strength 1000 H At 1800f98

2000 psi | 14 MPa
