Incoloy® 800HT High-Temperature Alloy Sheet
Incoloy® 800HT High-Temperature Alloy Sheet
SKU:NIC-15ca9b
Experience unparalleled strength and resistance with the Incoloy® 800HT Sheet.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Incoloy® 800HT High-Temperature Alloy Sheet
$89.99
Quantity: 1
Claim Your Seller Account
Incoloy® 800HT High-Temperature Alloy Sheet
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Incoloy® 800HT High-Temperature Alloy Sheet is a premium nickel-iron-chromium alloy renowned for its exceptional strength and superior resistance to oxidation, carburization, and corrosion in high-temperature environments. With a stable austenitic structure at elevated temperatures, this sheet is perfect for applications including process piping, heat exchangers, carburizing equipment, and more. Compliant with ASME SB-409, ASTM B409, and UNS N08811 specifications, this sheet guarantees reliability and longevity in demanding industrial settings.
Product Specifications
Nickel Alloy Compositions Alloy
Incoloy 800HT
Nickel Alloy Compositions Astm Specification
ASME SB-409 | ASTM B409 | UNS N08811
Nickel Alloy Compositions Basic Composition
0.015% Max. Sulphur | 0.10% Carbon | 0.60% Aluminum | 0.60% Titanium | 0.75% Max. Copper | 1.0% Max. Silicon | 1.20% Aluminum +Titanium | 1.50% Max. Manganese | 23.0% Chrominum | 35.0% Nickel | 39.5% Min. Iron
Nickel Alloy Compositions Density
0.287 lbs/in³ | 7.94 g/cm³
Specifications Material
Incoloy®
Specifications Shapeform
Sheets
Specifications Thickness
0.104 inches | 2.6416 mm
Mechanical Properties Melting Temperature Range
2475 to 2525 ºF | 1357 to 1385 ºC
Mechanical Properties Rupture Strength 1000 H At 1200f65
24000 psi | 165 MPa
Mechanical Properties Rupture Strength 1000 H At 1300f70
15000 psi | 105 MPa
Mechanical Properties Rupture Strength 1000 H At 1400f76
10000 psi | 70 MPa
Mechanical Properties Rupture Strength 1000 H At 1600f87
4700 psi | 32 MPa
Mechanical Properties Rupture Strength 1000 H At 1800f98
2000 psi | 14 MPa
