Industrial Brass Ball Check Valves - NPT Connection, NPT Nipple, NPT Adapter
Industrial Brass Ball Check Valves - NPT Connection, NPT Nipple, NPT Adapter
SKU:CHE-f8998a
Premium Industrial Brass Ball Check Valves for precise fluid control in industrial applications, with high pressure capability & minimal seat leakage.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Industrial Brass Ball Check Valves - NPT Connection, NPT Nipple, NPT Adapter
$39.99
Quantity: 1
Claim Your Seller Account
Industrial Brass Ball Check Valves - NPT Connection, NPT Nipple, NPT Adapter
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your fluid control systems with our Industrial Brass Ball Check Valves. Precision-engineered with brass material, 304 SS ball, and metal-to-metal construction, these valves ensure optimal performance with liquids or gases. Features include high pressure capability, choice of cracking pressure, and minimal seat leakage. With compliance to stringent industry standards and a maximum operating pressure of 2000 psig, these valves guarantee reliable operation in industrial settings.
Product Specifications
Dimensions Total Length
1.38 in
Dimensions Width Across Flats Hex
9/16 in
Features Features
All metal construction Long life operation Choice of cracking pressure High pressure capability
Flow Data Air Flow At 100 Psig
781 ft³/h
Flow Data Water Flow At 100 Psig
1.9 gpm
Specifications Additional Wetted Material
Loctite 609 / 680
Specifications Ball Material
304 SS
Specifications Connection A
1/4" NPT Male
Specifications Connection B
1/4" NPT Male
Specifications Cracking Pressure
15 psig
Specifications Cv
0.190
Specifications Material
Brass
Specifications Maximum Operating Pressure Gauge
2000 psig
Specifications Maximum Temperature
300 ºF
Specifications Seat Leakage
20 SSCM (max.) air flow at 25 psi differential
