Industrial Foot-Operated Hydraulic Pumps - FSP Series
Industrial Foot-Operated Hydraulic Pumps - FSP Series
SKU:HYD-81bc5f
Reliable industrial foot-operated hydraulic pumps for emergency hydraulic power needs. Stainless steel and bronze options available.
Regular price
$517.00
Regular price
Sale price
$517.00
Unit price
per
Initiate Order
Industrial Foot-Operated Hydraulic Pumps - FSP Series
$517.00
Quantity: 1
Claim Your Seller Account
Industrial Foot-Operated Hydraulic Pumps - FSP Series
$517.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Industrial Foot-Operated Hydraulic Pumps - FSP Series offer a reliable and cost-effective solution for developing or increasing pressure in hydraulic systems. Featuring a durable steel body with a hard chrome plated piston, these pumps are designed for emergency use, providing hydraulic power for various applications such as operating presses, valves, and safety locks. With maximum pressure rating up to 250 PSI, these pumps come in flange mount versions and are available in stainless steel or bronze designs, making them ideal for medical, food handling, corrosive environments, and wash-down applications.
Product Specifications
Specifications Adjustable Overload Relief Valve
No
Specifications Body Material
Steel
Specifications Foot Lever Load Per 100 Psi
37.0 lb
Specifications Inlet Port Size Nptf
3/8
Specifications List Price
517 USD
Specifications Manual Pressure Release Valve
No
Specifications Maximum Pressure Rating
250 psi
Specifications Mounting
Flange Mounted
Specifications Net Weight
11 lb
Specifications Oil Reservoir
false
Specifications Operating Lever Size
24 in
Specifications Outlet Port Size Nptf
3/8
Specifications Piston
Hard Chrome Plated
Specifications Piston Diameter
2 in
Specifications Series
FSP-PL
Specifications Volume Per Stroke
4.71 in³
Technical Information 0
Limited WarrantyAll Star pumps are covered by a limited warranty on materials and workmanship for one year from the date of manufacture. Star will repair or replace at its option any pump in which Star finds manufacturing defects. In order to get warranty service a pump must be returned to the Star plant freight prepaid with a written explanation of the problem.Technical DataLight hydraulic oil is recommended for use with Star pumps. Oils with SUS viscosity of 75 to 150 at 100 degrees Fahrenheit will give satisfactory performance (ISO grade 15, 22, or 32). In an emergency situation when the above oils are not available, use 5 W or 10 W motor oil or automatic transmission fluid.All exposed surfaces of standard Star pumps are painted with one coat of industrial quality paint. Pumps painted with special colors with two coat finishes, or with prime coat only, and pumps with special plated or polished parts, are also available.
