Industrial-Grade Aluminum Tread Plate 6061-T6, 0.125in Thickness, 60x192
Industrial-Grade Aluminum Tread Plate 6061-T6, 0.125in Thickness, 60x192
SKU:ALU-a60d7b
Premium Aluminum Tread Plate 6061-T6, 0.125in Thickness, Mill Finish, for Heavy-Duty Applications
Regular price
$249.99
Regular price
Sale price
$249.99
Unit price
per
Initiate Order
Industrial-Grade Aluminum Tread Plate 6061-T6, 0.125in Thickness, 60x192
$249.99
Quantity: 1
Claim Your Seller Account
Industrial-Grade Aluminum Tread Plate 6061-T6, 0.125in Thickness, 60x192
$249.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Our Aluminum Tread Plate, Grade 6061-T6, combines affordability and versatility, offering exceptional mechanical properties, corrosion resistance, and workability. With a mill finish and a thickness of 0.125 inches, it is ideal for heavy-duty structures, truck bodies, marine applications, and more. This plate is weldable, brazeable, and showcases excellent strength with enhanced corrosion resistance, meeting the stringent standards required for industrial and institutional use.
Product Specifications
Aluminum Alloy Designations 0
The aluminum industry uses a four-digit index system for the designation of its wrought aluminum alloys.As outlined below, the first digit indicates the alloy group according to the major alloying elements.1xxx SeriesIn this group minimum aluminum content is 99% and there is no major alloying element. The second digit indicates modifications in impurity limits. If the second digit is zero, there is no special control on individual impurities. Digits 1 through 9, which are assigned consecutively as needed, indicate special control of one or more individual impurities. The last two digits indicate specific minimum aluminum content. Although the absolute minimum aluminum content in this group is 99%, the minimum for certain grades is higher than 99%, and the last two digits represent the hundredths of a per cent over 99. Thus, 1030 would indicate 99.30% minimum aluminum. without special control on individual impurities. The designations 1130, 1230, 1330, etc.. indicate the same purity with special control on one or more impurities. Likewise 1100 indicates minimum aluminum content of 99.00% with individual impurity control.2xxx through 9xxx SeriesThe major alloying elements are indicated by the first digit, as follows: 2xxx Copper3xxx Manganese4xxx Silicon5xxx Magnesium6xxx Magnesium and silicon7xxx Zinc8xxx Other element9xxx Unused seriesThe second digit indicates alloy modification. If the second digit is zero. it indicates the original alloy: digits 1 through 9, which are assigned consecutively, indicate alloy modifications. The last two digits have no special significance, serving only to identify the different alloys in the group.Experimental AlloysExperimental alloys are designated according to the four digit system, but they are prefixed by the letter X. The prefix is dropped when the alloy becomes standard. During development, and before they are designated as experimental, new alloys are identified by serial numbers assigned by their originators. Use of the serial number is discontinued when the X number is assigned.
Comparative Characteristics And Applications Applications
Heavy-duty structures requiring good corrosion resistance, truck and marine, railroad cars, furniture, pipelines
Comparative Characteristics And Applications Arc Weldability
A
Comparative Characteristics And Applications Brazeability
A
Comparative Characteristics And Applications Gas Weldability
A
Comparative Characteristics And Applications Mechinability
C
Comparative Characteristics And Applications Resistance Spot And
A
Comparative Characteristics And Applications Resistance To Corro
B
Comparative Characteristics And Applications Stress Corrosion Cr
A
Comparative Characteristics And Applications Workability Cold
C
Specifications Density
0.098 lbs/in³
Specifications Finish
Mill
Specifications Grade
6061
Specifications Length
192
Specifications Material
Aluminum
Specifications Series
6061-T6
Specifications Shapeform
Plates
Specifications Size
60 x 192
Specifications Specific Gravity
2.70
Specifications Temper
T6
Specifications Thickness
0.125 inches | 3.125 mm
Specifications Weight Per Plate
152.32 lbs | 69.00096 kg
Specifications Width
60
Mechanical Properties Elongation Percent In 2 Inches
12
Mechanical Properties Fatigue Endurance Limit
14 ksi
Mechanical Properties Hardness Brinnel Number
95
Mechanical Properties Modulus Of Elasticity
10.0 x 102 ksi
Mechanical Properties Ultimate Shearing Strength
30 ksi
Mechanical Properties Ultimate Strength
45 ksi
Mechanical Properties Yield Strength
40 ksi
