Industrial Grade Large Bipolar Electromagnet
Industrial Grade Large Bipolar Electromagnet
SKU:LAR-d9b9be
Industrial Grade Large Bipolar Electromagnet for efficient handling of steel bundles and more.
Regular price
$6,999.99
Regular price
Sale price
$6,999.99
Unit price
per
Initiate Order
Industrial Grade Large Bipolar Electromagnet
$6,999.99
Quantity: 1
Claim Your Seller Account
Industrial Grade Large Bipolar Electromagnet
$6,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Industrial Grade Large Bipolar Electromagnet features an extended parallel pole design, offering a superior reach-out of the magnetic field compared to flat-faced models. It allows both north and south poles to efficiently make contact with curved or irregular surfaces. With a capacity of 23000 lb and 1700 W power, this electromagnet is ideal for handling steel bundles, die blocks, castings, and more. Its custom replaceable pole shoes cater to diverse handling needs, while maintaining a safety factor of 2:1. Designed for industrial applications, this electromagnet ensures reliable performance and durability.
Product Specifications
Manufacturing Notes 0
Capacity ratings shown include a 2:1 safety factor.
Specifications Capacity
23000 lb
Specifications Dimension A
12 1/4 in
Specifications Dimension B
42 in
Specifications Dimension C
13 in
Specifications Dimension D
20 1/8 in
Specifications Power
1700 W
Specifications Weight
1070 lb
