Industrial Threaded Check Valves with Nitrile Seal

Name: Industrial Threaded Check Valves with Nitrile Seal
Brand: O'Keefe Controls Co.
SKU: CHE-716d11
Price: 49.99 USD
Availability: OutOfStock

SKU:CHE-716d11

Reliable Industrial Threaded Check Valves for precise fluid control in high-pressure systems

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Enhance fluid control with our Industrial Threaded Check Valves featuring a durable 440C-SS ball and 303 SS construction. Designed for long life operation and cost-effectiveness, these valves with Nitrile seal ensure reliable performance under high pressures. With a maximum operating pressure of 1400 kPa and minimal leakage rates, our valves offer efficiency and longevity.

Product Specifications

Dimensions Nose Diameter

4.45 mm

Dimensions Orifice Diameter

0.04 in | 1.02 mm

Dimensions Thread Size

Dimensions Total Length

12.7 mm

Dimensions Width Across Flats Hex

3 mm

Features Features

All metal construction option Long life operation Low cost

Specifications Ball Material

440C-SS

Specifications Connection A

M6 Threaded Insert O-Ring seal

Specifications Cv

0.036

Specifications Hex Type

Internal

Specifications Material

303 SS

Specifications Maximum Operating Pressure

1400 kPa

Specifications Nominal Orifice Size

Specifications Screened

None

Specifications Seal Material

Nitrile

Specifications Seat Leakage

20 SSCM (max.) air flow at 25 psi differential

Specifications Thread

Male

Industrial Threaded Check Valves with Nitrile Seal
