Inovatec VA Series 890mm Gyrate Polishing Machine

Name: Inovatec VA Series 890mm Gyrate Polishing Machine
Brand: Inovatec Machinery
SKU: MAS-a231cf
Price: 5499.99 USD
Availability: OutOfStock

SKU:MAS-a231cf

Achieve high-quality metal finishes efficiently with the Inovatec Gyrate Polishing Machine - ideal for jewelry, watch components, and more.

$5,499.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Inovatec VA Series 890mm Gyrate Polishing Machine is a high-energy mass finishing solution designed for efficient and precise metal finishing. With a patented small gap design, it enables polishing of intricate and thin workpieces like jewelry parts and watch components. This user-friendly machine reduces manual handling, features automatic heat radiation, and offers speed and timer control for optimal results. Ideal for various applications including post-processing of 3D printed parts, it ensures high-quality finishes in a short time, making it a valuable asset for industrial and institutional users.

Product Specifications

Applications

Watch components PolishingJewelry parts PolishingElectric components3D Printed parts post processingAmber PolishingCoin Polishing

Dimensions Height

1440 mm

Dimensions Length

890 mm

Dimensions Width

800 mm

Features

Grinding barrel and rotating disc pendants of Dow chemical PUThe gap is adjusted by the helix deviceAutomatic heat radiationEquipped with speed control, timer control and forward/reverse movementAutomatic water recyclingCompound dosing system for wet machine

Specifications Barrel Speed

0 to 400 rpm

Specifications Frequency

50 to 60 Hz

Specifications Maximal Workpiece

30 mm

Specifications Motor Power

2.2 kW

Specifications Motor Speed

1430 rpm

Specifications Total Capacity

38 L

Specifications Voltage

380 V

Specifications Weight

220 kg
