Inovatec VA Series 972mm Gyrate Polishing Machine
Inovatec VA Series 972mm Gyrate Polishing Machine
SKU:MAS-0c6d07
Achieve precise and efficient metal finishing with the Inovatec VA Series 972mm Gyrate Polishing Machine.
Regular price
$6,599.99
Regular price
Sale price
$6,599.99
Unit price
per
Initiate Order
Inovatec VA Series 972mm Gyrate Polishing Machine
$6,599.99
Quantity: 1
Claim Your Seller Account
Inovatec VA Series 972mm Gyrate Polishing Machine
$6,599.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Inovatec VA Series Gyrate Polishing Machine revolutionizes mass finishing with its high-energy performance and precise polishing capabilities. Designed for maximum efficiency, this machine reduces material handling and manual labor in metal finishing processes. With its patented small gap design, it can delicately polish thin parts like earrings and pendants, making it ideal for intricate workpieces. Equipped with advanced features including automatic heat radiation, speed control, timer settings, and compound dosing system, it offers versatility for a wide range of applications from watch components to 3D printed parts post-processing.
Product Specifications
Applications
Watch components PolishingJewelry parts PolishingElectric components3D Printed parts post processingAmber PolishingCoin Polishing
Dimensions Height
1220 mm
Dimensions Length
972 mm
Dimensions Width
660 mm
Features
Grinding barrel and rotating disc pendants of Dow chemical PUThe gap is adjusted by the helix deviceAutomatic heat radiationEquipped with speed control, timer control and forward/reverse movementAutomatic water recyclingCompound dosing system for wet machine
Specifications Barrel Speed
0 to 450 rpm
Specifications Frequency
50 to 60 Hz
Specifications Maximal Workpiece
20 mm
Specifications Motor Power
0.37 kW
Specifications Motor Speed
1340 rpm
Specifications Number Of Motors
2
Specifications Total Capacity
9 x 2 L
Specifications Voltage
220 V
Specifications Weight
160 kg
