The Inovatec VB(B) Series 2500L Vibratory Finishing Machine is designed for mass finishing of large-sized mechanical parts with precision and efficiency. Featuring a 2500L total volume, heavy-duty components sourced from top-quality materials like Dow Chemicals, and a durable vibration motor from Shanghai Vibration Co., this machine ensures superior wear resistance, electrical conductivity, brightness, and more. With adjustable settings, stress-relieved construction, and wear-resistant PU lining, the VB(B) Series offers high-performance finishing for metal parts, meeting critical pre-finishing standards for institutional procurement requirements.
Product Specifications
Features
Hot-poured PU and a heavy-duty vibration motor are the primary components in our high-performance vibratory finishers. We make our polyurethane using raw materials sourced from Dow Chemicals, USA. We use an automatic casting machine to solidify the PU, then cure it at a controlled temperature for 24 hours.The sintered PU has 90-D hardness, ensuring wear resistance and durable performance. We use heavy-duty motor from Shanghai Vibration Co. With proper maintenance, it can last more than five years.Using a vibratory finisher VB(B) series machine will result in the following:Better wear resistanceElectrical conductivityBrightnessCorrosion resistancePaintabilityBond to rubberChemical resistanceHarness
Features And Applications
Digital process timerWide opening for big size partsStress relieved and enhanced with blastingAdjustable imbalance weightsAdjustable vibration intensityWear resistant PU lining from Dow ChemicalsHot-poured PU and a heavy-duty vibration motor are the primary components in our high-performance vibratory finishers. We make our polyurethane using raw materials sourced from Dow Chemicals, USA. We use an automatic casting machine to solidify the PU, then cure it at a controlled temperature for 24 hours.The sintered PU has 90-D hardness, ensuring wear resistance and durable performance. We use heavy-duty motor from Shanghai Vibration Co. With proper maintenance, it can last more than five years.Using a vibratory finisher VB(B) series machine will result in the following:Better wear resistanceElectrical conductivityBrightnessCorrosion resistancePaintabilityBond to rubberChemical resistanceHarness
Optional Settings
Sound coverCompound dosing pumpVariable frequency drivesControl box standing on the floor or hang on the wall
Specifications Machine Height H
1350 mm
Specifications Maximum Overall Dimension A
2300 mm
Specifications Motor Installation Tube Diameter C
850 mm
Specifications Motor Power
18.5 kW
Specifications Processing Bowl Width D Diameter
650 mm
Specifications Total Volume
2500 L
Specifications Tunnel Depth E
850 mm
Specifications Type
Vibratory
Specifications Weight
3000 kg
