Inovatec VB(B) Series 30L Vibratory Finishing Machine
Inovatec VB(B) Series 30L Vibratory Finishing Machine
SKU:MAS-ccd687
Achieve superior metal part finishes with Inovatec VB(B) 30L Vibratory Finisher. Durable PU components and adjustable settings for optimal results.
Regular price
$2,499.99
Regular price
Sale price
$2,499.99
Unit price
per
Initiate Order
Inovatec VB(B) Series 30L Vibratory Finishing Machine
$2,499.99
Quantity: 1
Claim Your Seller Account
Inovatec VB(B) Series 30L Vibratory Finishing Machine
$2,499.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your industrial finishing processes with the Inovatec VB(B) Series 30-liter vibratory finishing machine. Perfect for large and heavy metal parts like gear housing and shafts, this high-performance equipment features hot-poured PU components for superior wear resistance and prolonged durability. With adjustable settings, wide part openings, and high vibration intensity, achieve impeccable surface finishes with ease. Boost wear resistance, electrical conductivity, brightness, and more with this reliable vibratory finisher.
Product Specifications
Features
Hot-poured PU and a heavy-duty vibration motor are the primary components in our high-performance vibratory finishers. We make our polyurethane using raw materials sourced from Dow Chemicals, USA. We use an automatic casting machine to solidify the PU, then cure it at a controlled temperature for 24 hours.The sintered PU has 90-D hardness, ensuring wear resistance and durable performance. We use heavy-duty motor from Shanghai Vibration Co. With proper maintenance, it can last more than five years.Using a vibratory finisher VB(B) series machine will result in the following:Better wear resistanceElectrical conductivityBrightnessCorrosion resistancePaintabilityBond to rubberChemical resistanceHarness
Features And Applications
Digital process timerWide opening for big size partsStress relieved and enhanced with blastingAdjustable imbalance weightsAdjustable vibration intensityWear resistant PU lining from Dow Chemicals
Optional Settings
Sound coverCompound dosing pumpVariable frequency drivesControl box standing on the floor or hang on the wall
Specifications Machine Height H
800 mm
Specifications Maximum Overall Dimension A
670 mm
Specifications Motor Installation Tube Diameter C
136 mm
Specifications Motor Power
0.5 kW
Specifications Processing Bowl Width D Diameter
184 mm
Specifications Total Volume
30 L
Specifications Tunnel Depth E
200 mm
Specifications Type
Vibratory
Specifications Weight
85 kg
