Inovatec VB(B) Series 400L Vibratory Finishing Machine
Inovatec VB(B) Series 400L Vibratory Finishing Machine
SKU:MAS-d4ad3a
Achieve precision finishes on large parts with the Inovatec VB(B) Series 400L Vibratory Finishing Machine. Equipped for durability and performance with high-quality components.
Regular price
$5,999.99
Regular price
Sale price
$5,999.99
Unit price
per
Initiate Order
Inovatec VB(B) Series 400L Vibratory Finishing Machine
$5,999.99
Quantity: 1
Claim Your Seller Account
Inovatec VB(B) Series 400L Vibratory Finishing Machine
$5,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Inovatec VB(B) Series 400L Vibratory Finishing Machine is designed for processing large mechanical parts with precision and efficiency. Featuring a wide chamber wall and durable construction, this vibratory finisher uses high-speed vibrations to achieve superior surface finishes. With optional settings for sound cover, compound dosing pump, and more, it offers versatility and customization. The machine utilizes high-quality components like wear-resistant PU lining and a heavy-duty vibration motor, ensuring long-lasting performance and optimal results. Enhance your metal parts with better wear resistance, electrical conductivity, brightness, and more with the Inovatec VB(B) Series.
Product Specifications
Features
Hot-poured PU and a heavy-duty vibration motor are the primary components in our high-performance vibratory finishers. We make our polyurethane using raw materials sourced from Dow Chemicals, USA. We use an automatic casting machine to solidify the PU, then cure it at a controlled temperature for 24 hours.The sintered PU has 90-D hardness, ensuring wear resistance and durable performance. We use heavy-duty motor from Shanghai Vibration Co. With proper maintenance, it can last more than five years.Using a vibratory finisher VB(B) series machine will result in the following:Better wear resistanceElectrical conductivityBrightnessCorrosion resistancePaintabilityBond to rubberChemical resistanceHarness
Features And Applications
Digital process timerWide opening for big size partsStress relieved and enhanced with blastingAdjustable imbalance weightsAdjustable vibration intensityWear resistant PU lining from Dow ChemicalsHot-poured PU and a heavy-duty vibration motor are the primary components in our high-performance vibratory finishers. We make our polyurethane using raw materials sourced from Dow Chemicals, USA. We use an automatic casting machine to solidify the PU, then cure it at a controlled temperature for 24 hours.The sintered PU has 90-D hardness, ensuring wear resistance and durable performance. We use heavy-duty motor from Shanghai Vibration Co. With proper maintenance, it can last more than five years.Using a vibratory finisher VB(B) series machine will result in the following:Better wear resistanceElectrical conductivityBrightnessCorrosion resistancePaintabilityBond to rubberChemical resistanceHarness
Optional Settings
Sound coverCompound dosing pumpVariable frequency drivesControl box standing on the floor or hang on the wall
Specifications Machine Height H
1040 mm
Specifications Maximum Overall Dimension A
1410 mm
Specifications Motor Installation Tube Diameter C
633 mm
Specifications Motor Power
5.0 kW | 6.0 kW
Specifications Processing Bowl Width D Diameter
320 mm
Specifications Total Volume
400 L
Specifications Tunnel Depth E
450 mm
Specifications Type
Vibratory
Specifications Weight
850 kg
