Inovatec VB(B) Series 63L Vibratory Finishing Machine
Inovatec VB(B) Series 63L Vibratory Finishing Machine
SKU:MAS-0d5b80
Achieve superior metal part finishing with Inovatec's high-performance 63L Vibratory Finisher.
Regular price
$2,899.99
Regular price
Sale price
$2,899.99
Unit price
per
Initiate Order
Inovatec VB(B) Series 63L Vibratory Finishing Machine
$2,899.99
Quantity: 1
Claim Your Seller Account
Inovatec VB(B) Series 63L Vibratory Finishing Machine
$2,899.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Inovatec VB(B) Series 63L Vibratory Finishing Machine is designed for processing large-sized and heavy mechanical parts with precision and efficiency. With a wide chamber wall and the ability to use various tumbling media like pebble stones and tiles, this machine offers exceptional surface finishing results. Its features include adjustable vibration intensity, wear-resistant PU lining, and a heavy-duty vibration motor for long-lasting performance. Ideal for pre-finishing metal parts, it enhances wear resistance, brightness, corrosion resistance, and more.
Product Specifications
Features
Hot-poured PU and a heavy-duty vibration motor are the primary components in our high-performance vibratory finishers. We make our polyurethane using raw materials sourced from Dow Chemicals, USA. We use an automatic casting machine to solidify the PU, then cure it at a controlled temperature for 24 hours.The sintered PU has 90-D hardness, ensuring wear resistance and durable performance. We use heavy-duty motor from Shanghai Vibration Co. With proper maintenance, it can last more than five years.Using a vibratory finisher VB(B) series machine will result in the following:Better wear resistanceElectrical conductivityBrightnessCorrosion resistancePaintabilityBond to rubberChemical resistanceHarness
Features And Applications
Digital process timerWide opening for big size partsStress relieved and enhanced with blastingAdjustable imbalance weightsAdjustable vibration intensityWear resistant PU lining from Dow ChemicalsHot-poured PU and a heavy-duty vibration motor are the primary components in our high-performance vibratory finishers. We make our polyurethane using raw materials sourced from Dow Chemicals, USA. We use an automatic casting machine to solidify the PU, then cure it at a controlled temperature for 24 hours.The sintered PU has 90-D hardness, ensuring wear resistance and durable performance. We use heavy-duty motor from Shanghai Vibration Co. With proper maintenance, it can last more than five years.Using a vibratory finisher VB(B) series machine will result in the following:Better wear resistanceElectrical conductivityBrightnessCorrosion resistancePaintabilityBond to rubberChemical resistanceHarness
Optional Settings
Sound coverCompound dosing pumpVariable frequency drivesControl box standing on the floor or hang on the wall
Specifications Machine Height H
910 mm
Specifications Maximum Overall Dimension A
830 mm
Specifications Motor Installation Tube Diameter C
114 mm
Specifications Motor Power
0.75 kW | 1.1 kW
Specifications Processing Bowl Width D Diameter
280 mm
Specifications Total Volume
63 L
Specifications Tunnel Depth E
245 mm
Specifications Type
Vibratory
Specifications Weight
110 kg
