Inovatec VB(B) Series 660L Vibratory Finishing Machine
Inovatec VB(B) Series 660L Vibratory Finishing Machine
SKU:MAS-d3c099
Experience superior metal surface finishing with Inovatec's VB(B) Series 660L Vibratory Finishing Machine.
Regular price
$8,499.99
Regular price
Sale price
$8,499.99
Unit price
per
Initiate Order
Inovatec VB(B) Series 660L Vibratory Finishing Machine
$8,499.99
Quantity: 1
Claim Your Seller Account
Inovatec VB(B) Series 660L Vibratory Finishing Machine
$8,499.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your surface finishing process with the Inovatec VB(B) Series 660L Vibratory Finishing Machine. Designed with a wide chamber wall, this high-performance machine accommodates large mechanical parts like gear components and shafts. Its hot-poured PU and heavy-duty vibration motor ensure exceptional wear resistance and durability, meeting the stringent standards of institutional buyers. With features like adjustable imbalance weights, adjustable vibration intensity, and wear-resistant PU lining, this machine delivers superior results in pre-finishing metal parts, enhancing wear resistance, electrical conductivity, brightness, and more.
Product Specifications
Features
Hot-poured PU and a heavy-duty vibration motor are the primary components in our high-performance vibratory finishers. We make our polyurethane using raw materials sourced from Dow Chemicals, USA. We use an automatic casting machine to solidify the PU, then cure it at a controlled temperature for 24 hours.The sintered PU has 90-D hardness, ensuring wear resistance and durable performance. We use heavy-duty motor from Shanghai Vibration Co. With proper maintenance, it can last more than five years.Using a vibratory finisher VB(B) series machine will result in the following:Better wear resistanceElectrical conductivityBrightnessCorrosion resistancePaintabilityBond to rubberChemical resistanceHarness
Features And Applications
Digital process timerWide opening for big size partsStress relieved and enhanced with blastingAdjustable imbalance weightsAdjustable vibration intensityWear resistant PU lining from Dow ChemicalsHot-poured PU and a heavy-duty vibration motor are the primary components in our high-performance vibratory finishers. We make our polyurethane using raw materials sourced from Dow Chemicals, USA. We use an automatic casting machine to solidify the PU, then cure it at a controlled temperature for 24 hours.The sintered PU has 90-D hardness, ensuring wear resistance and durable performance. We use heavy-duty motor from Shanghai Vibration Co. With proper maintenance, it can last more than five years.Using a vibratory finisher VB(B) series machine will result in the following:Better wear resistanceElectrical conductivityBrightnessCorrosion resistancePaintabilityBond to rubberChemical resistanceHarness
Optional Settings
Sound coverCompound dosing pumpVariable frequency drivesControl box standing on the floor or hang on the wall
Specifications Machine Height H
1140 mm
Specifications Maximum Overall Dimension A
1820 mm
Specifications Motor Installation Tube Diameter C
910 mm
Specifications Motor Power
5.5 kW | 7.5 kW
Specifications Processing Bowl Width D Diameter
370 mm
Specifications Total Volume
660 L
Specifications Tunnel Depth E
490 mm
Specifications Type
Vibratory
Specifications Weight
1850 kg
