Inovatec Vibratory Finisher VB(B) Series 920L
Inovatec Vibratory Finisher VB(B) Series 920L
SKU:MAS-515afb
Inovatec Vibratory Finisher: Achieve superior surface finishes with our VB(B) Series 920L machine. Perfect for large mechanical parts.
Regular price
$10,999.99
Regular price
Sale price
$10,999.99
Unit price
per
Initiate Order
Inovatec Vibratory Finisher VB(B) Series 920L
$10,999.99
Quantity: 1
Claim Your Seller Account
Inovatec Vibratory Finisher VB(B) Series 920L
$10,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Inovatec Vibratory Finisher VB(B) Series 920L is designed for processing large mechanical parts like gear housing, gear parts, and shafts. With a 920L total volume and high-speed vibratory motion, it ensures optimal surface finish. Featuring wear-resistant PU lining, adjustable settings, and a heavy-duty vibration motor, this machine offers better wear resistance, electrical conductivity, brightness, corrosion resistance, and more. Ideal for pre-finishing metal parts with enhanced durability and performance.
Product Specifications
Features
Hot-poured PU and a heavy-duty vibration motor are the primary components in our high-performance vibratory finishers. We make our polyurethane using raw materials sourced from Dow Chemicals, USA. We use an automatic casting machine to solidify the PU, then cure it at a controlled temperature for 24 hours.The sintered PU has 90-D hardness, ensuring wear resistance and durable performance. We use heavy-duty motor from Shanghai Vibration Co. With proper maintenance, it can last more than five years.Using a vibratory finisher VB(B) series machine will result in the following:Better wear resistanceElectrical conductivityBrightnessCorrosion resistancePaintabilityBond to rubberChemical resistanceHarness
Features And Applications
Digital process timerWide opening for big size partsStress relieved and enhanced with blastingAdjustable imbalance weightsAdjustable vibration intensityWear resistant PU lining from Dow ChemicalsHot-poured PU and a heavy-duty vibration motor are the primary components in our high-performance vibratory finishers. We make our polyurethane using raw materials sourced from Dow Chemicals, USA. We use an automatic casting machine to solidify the PU, then cure it at a controlled temperature for 24 hours.The sintered PU has 90-D hardness, ensuring wear resistance and durable performance. We use heavy-duty motor from Shanghai Vibration Co. With proper maintenance, it can last more than five years.Using a vibratory finisher VB(B) series machine will result in the following:Better wear resistanceElectrical conductivityBrightnessCorrosion resistancePaintabilityBond to rubberChemical resistanceHarness
Optional Settings
Sound coverCompound dosing pumpVariable frequency drivesControl box standing on the floor or hang on the wall
Specifications Machine Height H
1350 mm
Specifications Maximum Overall Dimension A
1930 mm
Specifications Motor Installation Tube Diameter C
610 mm
Specifications Motor Power
11 kW
Specifications Processing Bowl Width D Diameter
560 mm
Specifications Total Volume
920 L
Specifications Tunnel Depth E
575 mm
Specifications Type
Vibratory
Specifications Weight
2200 kg
