Intel Core Rugged Embedded Computer DV-1100
Intel Core Rugged Embedded Computer DV-1100
SKU:RUG-039343
Experience enhanced computing with the Intel Core Rugged Embedded Computer DV-1100, ideal for smart manufacturing and space-constrained setups.
Regular price
$1,799.99
Regular price
Sale price
$1,799.99
Unit price
per
Initiate Order
Intel Core Rugged Embedded Computer DV-1100
$1,799.99
Quantity: 1
Claim Your Seller Account
Intel Core Rugged Embedded Computer DV-1100
$1,799.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Intel Core Rugged Embedded Computer DV-1100 is a high-performance edge computing solution designed for smart manufacturing, machine vision, and other space-constrained applications. Powered by Intel's latest 13th and 12th Gen. Core processors, this compact device ensures outstanding processing capabilities for enhanced decision-making and production efficiency. With features like high-speed I/O interfaces, multiple expansion slots, and a rugged design meeting industrial certifications, the DV-1100 offers reliability and performance in demanding environments.
Product Specifications
Additional Information Additional Information
Balancing Performance and CostThe DV-1100 has a compact body and supports a 13th/12th generation Intel® Core⢠processor. It provides sufficient computing performance for multitasking and diverse applications while balancing performance and cost.Compact SizeThe DV-1100 measures only 224.1 x 162 x 62mm, making it easy to install anywhere, including in space-constrained applications.Stunning Transfer and Access SpeedsThe DV-1100 has high-speed I/O interfaces, including 2.5G LAN and 10Gbps USB 3.2 Gen2x1. Storage support includes 2.5ⳠHDD/SSD and high-speed NVMe SSD.Excellent Extension DesignThe DV-1100 has built-in M.2 Key B, M.2 Key E, and M.2 Key M slots for flexible wireless (5G, Wi-Fi, GNSS) and storage selection according to application requirementsVarious Industry CertificationsThe DV-1100's rugged design meets various industrial-grade and industrial certifications, such as EMC standards in industrial environments (EN 61000-6-2/4), US military shock vibration standards (MIL-STD-810H), railway computing EN50155 (EN 50121-3-2 only), and more.
Audio Audio Codec
Realtek® ALC888, High Definition Audio
Audio Line Out
1x Line-Out, Phone Jack 3.5 mm
Audio Mic In
1x Mic-in, Phone Jack 3.5 mm
Environment Electromagnetic Compatibility Emc
CE, UKCA, FCC, ICES-003 Class AEN IEC 61000-6-4 / EN IEC 61000-6-2 (24VDC Input Only)EN 50155 (EN 50121-3-2 Only)E-mark (Pending)
Environment Electromagnetic Interference Emi
CISPR 32 Conducted & Radiated: Class AEN/BS EN 50121-3-2 Conducted & Radiated: Class AEN/BS EN IEC 61000-3-2 Harmonic current emissions: Class AEN/BS EN 61000-3-3 Voltage fluctuations & flickerFCC 47 CFR Part 15B, ICES-003 Conducted & Radiated: Class A
Environment Environmental Management System Ems
EN/IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kVEN/IEC 61000-4-3 RS: 80 MHz to 1000 MHz: 20 V/mEN/IEC 61000-4-4 EFT: AC Power: 2 kV; DC Power: 2 kV; Signal: 2 kVEN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kVEN/IEC 61000-4-6 CS: 10V(**Compliant with the standard when utilizing shielded cable.)EN/IEC 61000-4-8 PFMF: 50 Hz, 30AEN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 1 cycles at 60 Hz
Environment Non Condensing Relative Humidity Rh At 70 Degree Cel
95 %
Environment Note For Operating Temperature
PassMark Burn-In Test: 100% CPU, 2D/3D Graphics (without thermal throttling)With extended temperature peripherals; Ambient with air flowAccording to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14
Environment Operating Temperature
35W TDP Processor: -40ºC to 70ºC65W TDP Processor: -40ºC to 55ºC (With External Fan Kit)
Environment Safety
Canadian Underwriters Laboratories (cUL) | Certification Body Scheme (CB) | European Norm (EN 62368-1) | International Electrotechnical Commission (IEC) | Underwriters Laboratories (UL)
Environment Shock
MIL-STD-810H
Environment Storage Temperature
-40 to 70 ºC
Environment Vibration
MIL-STD-810H
Expansion Combined Multiple Interface Cmi Inputoutput Io
1x CMI Interface for optional CMI-Display Module Expansion2x CMI Interface for optional CMI-COM/DIO Module Expansion
Expansion Control Function Module Cfm Interface
1x CFM IGN Interface for optional CFM-IGN Module Expansion
Expansion M2 Key B Socket
1x M.2 Key B Type 3042/3052 Socket (PCIe Gen 3x2 / USB3.2 Gen2 x1 / USB2.0 / SATA), Support 5G/Storage/Add-on Card Expansion1x M.2 Key B Type 2242 Socket (PCIe Gen 3x2 / USB2.0 / SATA ), Support Storage/Add-on Card Expansion
Expansion M2 Key E Socket
1x M.2 Key E Type 2230 Socket (PCIe Gen 3x2 / USB2.0), Support Wireless/Intel® CNVi Module Expansion
Expansion Subscriber Identity Module Sim Socket
1x Front Accessible Dual Nano SIM Socket
Features Features
Intel® 13/12th Gen. Core⢠i9/i7/i5/i3 Processors (max 65 W TDP)1x M.2 Key M Type 2280 Socket for PCIe Gen 4x4 NVMe Storage1x M.2 Key E Type 2230 Socket for Wireless/Intel CNVi Module Expansion1x M.2 Key B Type 3052/3042 Socket for 5G/Storage/Add-on Card Expansion1x M.2 Key B Type 2242 Socket for Storage/Add-on Card ExpansionOptional CMI & CFM Modules for I/O Expansion & Power Ignition Sensing FunctionWide operating temperature -40ºC to 70ºCSafety Standard: UL, cUL, CB, IEC, EN 62368-1
Graphics Common Management Interface Cmi Display
1x CMI Interface for Optional CMI-DP/CMI-HDMI Module Expansion
Graphics Displayport Dp
1x DisplayPort Connector: 3840 x 2160 at 60 Hz
Graphics Graphics Engine
Integrated Intel® UHD Graphics 770: Core⢠i9/i7/i5Integrated Intel® UHD Graphics 730: Core⢠i3Integrated Intel® UHD Graphics 710: Pentium®/Celeron®
Graphics Maximum Display Output
Supports Triple Independent Display
Graphics Video Graphics Array Vga
1x VGA Connector (1920 x 1200 at 60 Hz)
Inputoutput Io Ports Communication Port Com
2x RS-232/422/485 with Auto Flow Control Support 5V/12V, DB9
Inputoutput Io Ports Local Area Network Lan
1x 2.5GbE LAN, RJ45(Intel® I225)1x 1GbE LAN, RJ45(Intel® I219)
Inputoutput Io Ports Universal Serial Bus Usb
1x 10Gbps USB3.2 Gen 2x1, Type A2x 5 Gbps USB 3.2 Gen 1x1, Type A3x 480 Mbps USB2.0, Type A
Operating System Linux
Ubuntu 22.04
Operating System Microsoft Windows
Windows® 10 | Windows® 11
Physical Depth
162 mm
Physical Height
62 mm
Physical Width
224.1 mm
Power Power Button
1 x ATX Power On/Off Button
Power Power Input
9 to 48 VDC, 3-Pin Terminal Block
Power Power Mode Switch
1 x AT/ATX Mode Switch
Power Remote Power Light Emitting Diode Led
1x Remote Power LED, 2-Pin Terminal Block
Power Remote Power Onoff
1 x Remote Power On/Off, 2-Pin Terminal Block
Reliability And Protection Over Voltage Protection
Protection Range: 51~58VProtection Type: shut down operating voltage, re-power on at the present level to recover
Reliability And Protection Reverse Power Input Protection
Yes
