Meet your industrial needs with our Iron/Boron/Silicon (Fe77.5/B15/Si7.5) Wire. This pure metal alloy wire, offering a diameter of 0.05mm, boasts exceptional thermal, electrical, and mechanical properties suitable for various applications such as soft magnetic uses, brazing, and reinforcing fibers. With high tensile strength, low electrical resistivity, and a Curie temperature of 422 ºC, this wire is a reliable choice for manufacturing processes requiring precision and quality.
Product Specifications
Electrical Properties Electrical Resistivity
124 µΩ·cm
Magnetic Properties Curie Temperature
422 ºC
Material Material
Iron/Boron/SiliconMetallic glasses (glassy alloys) or amorphous metals. Uses include soft magnetic applications, brazing, coating and as reinforcing fibers.
Mechanical Properties Elongation At Break
2.3 %
Mechanical Properties Hardness Vickers
940 Kgf mm-2
Mechanical Properties Tensile Modulus
155.00 GPa
Specifications Diameter
0.05 mm
Specifications Form
Wire
Specifications Grade
Metallic Glass
Specifications Length
1 to 50 m
Specifications Tolerance For Length Round
-1 mm | +5 mm
Thermal Properties Coefficient Of Thermal Expansion At 20 Degree
8.700 x10-6 K-1
Thermal Properties Crystallization Temperature
553 ºC
Tolerances Disc Diameter Tolerance
10 %
Type Type
GlassGoodfellow offers two distinct types of glass products: The first are generally silica-based, non-crystalline (amorphous) solids which exhibit a glass transition and are brittle and transparent. The properties of glass materials can be readily modified to alter their optical performance and other characteristics. This type is available through Goodfellow's Ceramic and Glass Division. Generally, these products are made to order for customers, so we do not list them in our Catalog. Please contact us with your requirements. The second type of glass product is commonly referred to as "metallic glasses" or "glassy metals". In contrast to crystalline metals and alloys with highly ordered atomic structures, these are non-crystalline (amorphous) metals or, more usually, alloys. Our website details those glassy metals which are available from stock; please contact us if you are unable to find the item you specifically require.
