The ISO Grade Tungsten Carbide offers exceptional performance in general purpose machining of cast iron, non-ferrous, and non-metallic materials. With a nominal composition of 94% Tungsten Carbide and 6% Cobalt, this grade boasts a hardness of 91.8 Ra and a high density of 14.94 g/cc. The Ultra-Met Grade Z22 with ANSI Code C2 ensures reliable performance and extended tool life, supported by a Transverse Rupture Strength of 350 ksi. Perfect for precision machining applications, this grade meets stringent industry standards for quality and durability.
Product Specifications
Classifications Ansi Code
C2
Classifications Applications
General Purpose (Machining - Cast Iron, Non-Ferrous, and Non-Metalic Materials)
Classifications Grades
Tungsten Carbide
Classifications Grain Size
Fine
Classifications Ultra Met Grades
Z22
Nominal Composition Cobalt Co
6.00%
Nominal Composition Tungsten Carbide Wc
94.00%
Physical Properties Density
14.94 g/cc
Physical Properties Hardness Hra
91.8 Ra
Physical Properties Transverse Rupture Trs
350 ksi | 350000 psi
