Our Isolation Power Transformers are designed to ensure equipment safety by isolating them from direct power lines with nonconcentrically wound coils. These hospital-grade transformers with resettable circuit breakers meet low leakage current requirements for medical equipment. The primary and secondary windings are separated by insulation to prevent electrical connections, providing reliable protection from overload and short circuit conditions.
Product Specifications
Specifications Case Type
X
Specifications Connections
Leads
Specifications Depth D
2 in
Specifications Height H
1 15/16 in
Specifications Mounting Hole Size
3/16 in
Specifications Mounting Width
2 13/16 in
Specifications Output Wattage Va Rating
15 W
Specifications Primary Frequency
50 Hz | 60 Hz
Specifications Primary Voltage
115 V
Specifications Secondary Current
0.130 A
Specifications Secondary Voltage 5
115 V
Specifications Weight
1.40 lb
Specifications Width W
3 5/16 in
Technical Notes Technical Notes
Line cord, plug and receptacle are U.L. listed and verified to meet federal specifications.Connections are by leads, plugs and sockets.Hi-pot tested at 1,500 VRMS.
