Isolation Power Transformers - Hospital Grade with Resettable Circuit Breaker
Isolation Power Transformers - Hospital Grade with Resettable Circuit Breaker
SKU:POW-f87dff
Isolation Power Transformers for ultimate safety and reliability in medical environments.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Isolation Power Transformers - Hospital Grade with Resettable Circuit Breaker
$129.99
Quantity: 1
Claim Your Seller Account
Isolation Power Transformers - Hospital Grade with Resettable Circuit Breaker
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Our Isolation Power Transformers are purpose-built for isolating equipment from direct power connections, ensuring safety and reliability. Ideal for medical settings, these transformers meet stringent low leakage current requirements. Constructed with nonconcentrically wound coils and separate primary and secondary windings, they prevent electrical connection even under overload. The hospital-grade units feature a resettable circuit breaker for added protection against overloads and short circuits.
Product Specifications
Note Note
Split winding
Specifications Case Type
X
Specifications Connections
Leads
Specifications Depth D
2 1/8 in
Specifications Height H
2 9/32 in
Specifications Mounting Hole Size
3/16 in
Specifications Mounting Width
3 1/8 in
Specifications Output Wattage Va Rating
50 W
Specifications Primary Frequency
50 Hz | 60 Hz
Specifications Primary Voltage
115 V | 230 V
Specifications Secondary Current
0.435 A
Specifications Secondary Voltage 5
115 V
Specifications Weight
1.70 lb
Specifications Width W
3 11/16 in
Technical Notes Technical Notes
Line cord, plug and receptacle are U.L. listed and verified to meet federal specifications.Connections are by leads, plugs and sockets.Hi-pot tested at 1,500 VRMS.
