IST AG P1K0.0805.2P.B Platinum RTD Temperature Sensor
IST AG P1K0.0805.2P.B Platinum RTD Temperature Sensor
SKU:TEM-f2a113
High-performance IST AG P1K0.0805.2P.B Platinum RTD Temperature Sensor for accurate temperature measurements in diverse environments.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
IST AG P1K0.0805.2P.B Platinum RTD Temperature Sensor
$29.99
Quantity: 1
Claim Your Seller Account
IST AG P1K0.0805.2P.B Platinum RTD Temperature Sensor
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Discover the IST AG P1K0.0805.2P.B, a high-performance surface-mount temperature sensor designed for precise temperature measurements. With a resistivity of 1000 Ohms at 0°C and a temperature range from -50 to +150°C, this sensor ensures accurate readings in diverse environments. Meeting RoHS compliance and IEC 60751 F0.3 standards, it guarantees quality and safety. The lead-free tin-plated contacts and compact dimensions enhance installation flexibility and reliability.
Product Specifications
Dimensions Height
0.4 mm
Dimensions Length
2.0 mm
Dimensions Width
1.2 mm
Specifications Manufacturer Part Number
P1K0.0805.2P.B
Specifications Old Product Code
010.01047
Specifications Resistivity At 0 Degree Celsius C Temperature
1000 Ω
Specifications Restriction Of Hazardous Substances Directive Roh
Yes
Specifications Soldering Connection
Lead-free Tin Plated Contacts (96.5% Sn, 3% Ag, 0.5% Cu)
Specifications Temperature Coefficient Of Resistance Tcr
3850 ppm/K
Specifications Temperature Range
-50 to +150 ºC
Specifications Tolerance
International Electrotechnical Commission (IEC) 60751 F0.3 (IST AG Reference Class B)
Specifications Type
0805
