The IST USA LFS1K0 Conductivity Sensor is a cutting-edge solution for precise conductivity measurements in a wide range from 100 µS/cm to 200 mS/cm, extendable to 10 µS/cm to 200 mS/cm with cell-constant correction. Featuring a 4-electrode design with an integrated Pt1000 temperature sensor, this sensor ensures accurate readings even in extreme temperatures from -30 to +100 ºC. With compliant RoHS standards and platinum/nickel wire construction, this sensor guarantees reliability and efficiency for various applications.
Product Specifications
Dimensions Length
14.9 mm
Dimensions Length Tolerance
5.5 mm
Dimensions Width
0.65 mm
Specifications Conductivity Range
100 µS/cm to 200 mS/cm (Extended Range from 10 µS/cm to 200 mS/cm Possible with Cell-Constant Correction)
Specifications Layout
4 Electrodes and Integrated Temperature Sensor (Pt1000, Class F0.3)
Specifications Manufacturer Part Number
LFS1K0.1505.6W.B.010-6
Specifications Number Of Wires
6
Specifications Old Product Code
090.00078
Specifications Restriction Of Hazardous Substances Directive Roh
Yes
Specifications Temperature Range
-30 to +100 ºC
Specifications Wire Diameter
0.2 mm
Specifications Wire Length
10 mm
Specifications Wire Type
Platinum (Pt)/Nickel (Ni)
