JET Precision Variable Speed Milling Machine
JET Precision Variable Speed Milling Machine
SKU:MIL-00eb73
Experience precision milling with JET's Variable Speed Milling Machine, designed for quality cuts and ease of use.
Regular price
$15,699.00
Regular price
Sale price
$15,699.00
Unit price
per
Initiate Order
JET Precision Variable Speed Milling Machine
$15,699.00
Quantity: 1
Claim Your Seller Account
JET Precision Variable Speed Milling Machine
$15,699.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The JET Precision Variable Speed Milling Machine combines precision engineering with industry-leading features. With proprietary Meehanite® column castings, a hardened 10” x 50” table, and high precision spindle bearings, this machine ensures quality cuts. Featuring chrome lead screws, a one-shot lubrication system, and a three-stage power downfeed with automatic stop, it enhances usability. Meeting stringent industry standards, this machine is backed by the JET Two Year Warranty.
Product Specifications
Features Features
Chrome lead screws on X and Y axisHardened and ground tableHardened and ground table capable of supporting 840 poundsInternal coolant tank built into base for use with optional coolant system(coolant pump not included)JET's proprietary certified Meehanite® column castingsOne shot lubrication systemPrecision bored and honed milling headThree stage power downfeed with automatic stop
Technical Specs Brands
JET
Technical Specs Collet Capacity
1/8 to 5/8 in
Technical Specs Column Width
13 in
Technical Specs Height
89 in
Technical Specs Length
63 in
Technical Specs Maximum Distance Spindle To Column
7 in
Technical Specs Net Weight
1930 lb | 875 kg
Technical Specs Quill Diameter
3-3/8 in
Technical Specs Quill Down Feed Rates
0.0015 to 0.003 to 0.008
Technical Specs Saddle Width
20 in
Technical Specs Spindle Motor Phase
3
Technical Specs Spindle Motor Power
3 hp
Technical Specs Spindle Speeds
500 to 4200 rpm | 60 to 500 rpm
Technical Specs Spindle Taper
R8
Technical Specs Spindle Travel
5 in
Technical Specs Table Size
10 x 50 in
Technical Specs Travel Of Knee
6 1/8 in
Technical Specs T Slots Centers
2 1/2 in
Technical Specs Voltage
230 V | 460 V
Technical Specs Weight
2466 lb
Technical Specs Width
63 in
Technical Specs Working Table Cross Travel
14 3/4 in
Technical Specs Working Table Longitudinal Travel
34 1/4 in
Technical Specs Work Table
49 x 9 in
Technical Specs Work Table Weight Capacity
840 lb
