Jilson Inch Plastic Radial Bearings
Jilson Inch Plastic Radial Bearings
SKU:BEA-ecab54
High-quality Jilson Inch Plastic Radial Bearings for diverse applications in corrosive environments - non-magnetic and durable with top-grade materials. Custom fabricate to meet specific needs.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Jilson Inch Plastic Radial Bearings
$49.99
Quantity: 1
Claim Your Seller Account
Jilson Inch Plastic Radial Bearings
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Jilson Inch Plastic Radial Bearings offer top-grade performance in corrosive and wet environments, ideal for applications like hospital equipment due to their non-magnetic properties. With a width of 5/16 and load capacity ranging from 41-100 lbs, these bearings combine Acetal, Nylon, Stainless Steel, and more to meet diverse needs. Featuring a single row design, solid PBT housing, and PP races/cage, these bearings ensure reliability at 840 RPM in air. Upgrade to Jilson for outstanding durability and custom fabrication capabilities.
Product Specifications
Specifications Balls
SS
SPECIFICATIONS CAGE
PP
Specifications Inside Diameter
3/4
Specifications Inside Diameter Range
3/4 in
Specifications Load Capacity Dynamic Lbs
88
Specifications Load Capacity Dynamic Lbs Range
81-100
Specifications Load Capacity Static Lbs
44.2
Specifications Load Capacity Static Lbs Range
41-60
Specifications Max Rpm In Air
840
Specifications Notes
Jilson plastic ball bearings are well suited for other applications like wash down areas, where equipment is frequently wet and prone to rusting with conventional bearings. Corrosive environments, where bearings will be subject to chemical abrasiveness, a | We use top grade materials such as: Acetal, Nylon, Polypropylene, Polyethylene, KYNAR, PETP, PBT, PEEK, Ceramic and Stainless Steel in different combinations to meet specific needs. Jilsonâs housings for plastic bearings are made of high-grade, solid PBT
Specifications Outside Diameter
1.625
Specifications Outside Diameter Range
1-5/8 in
Specifications Races
PP
Specifications Rows
Single
Specifications Series
R12
Specifications Width
5/16
