Jilson Inch Radial Bearings
Jilson Inch Radial Bearings
SKU:BEA-133ae7
Precision-engineered Jilson Inch Radial Bearings for high-performance in sensitive environments. Corrosion-resistant with non-magnetic properties.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Jilson Inch Radial Bearings
$49.99
Quantity: 1
Claim Your Seller Account
Jilson Inch Radial Bearings
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Jilson Inch Radial Bearings are precision-engineered to deliver exceptional performance in demanding environments. Crafted using top-grade materials like Acetal, Nylon, and Stainless Steel with a Glass cage, these bearings offer superior corrosion resistance and non-magnetic properties, making them ideal for sensitive applications like hospital and wash-down areas. With a Static Load Capacity of 33 lbs, Dynamic Load Capacity of 42 lbs, and a Max RPM of 1600 in Air, these bearings ensure reliable operation even under heavy loads and high speeds. Designed for durability and longevity, Jilson's housings are constructed from high-grade solid PBT, providing robust support and stability.
Product Specifications
Specifications Balls
SS
SPECIFICATIONS CAGE
Glass
Specifications Inside Diameter
3/8
Specifications Inside Diameter Range
3/8 in
Specifications Load Capacity Dynamic Lbs
42
Specifications Load Capacity Dynamic Lbs Range
41-60
Specifications Load Capacity Static Lbs
33
Specifications Load Capacity Static Lbs Range
21-40
Specifications Max Rpm In Air
1600
Specifications Notes
Jilson plastic ball bearings are well suited for other applications like wash down areas, where equipment is frequently wet and prone to rusting with conventional bearings. Corrosive environments, where bearings will be subject to chemical abrasiveness, a | We use top grade materials such as: Acetal, Nylon, Polypropylene, Polyethylene, KYNAR, PETP, PBT, PEEK, Ceramic and Stainless Steel in different combinations to meet specific needs. Jilsonâs housings for plastic bearings are made of high-grade, solid PBT
Specifications Outside Diameter
.875
Specifications Outside Diameter Range
7/8 in
Specifications Races
Acetal
Specifications Rows
Single
Specifications Series
R06
Specifications Width
7/32
